BELDEN 74002E01305 Industrial Ethernet Cable
The DataTuff Industrial Ethernet Cat 5e Moderate Flexing Cable provides reliable data transmission with a 1 Gb/s capacity, suitable for indoor environments. Constructed with stranded 26 AWG copper conductors, it features a PVC oil-resistant jacket, foil and braid shielding, and 4 twisted pairs with polypropylene insulation. Compliant with ISO/IEC 11801 and EN 5073 standards, this cable is designed for high performance in industrial applications, with a temperature range of -40°C to +80°C, maximum tensile strength of 15 MPa, and an impedance of 100 Ohms. Ideal for robust, high-speed networking solutions.
BELDEN 74002E01305 Industrial Ethernet Cable Specifications:
- Conductor Material: 26 AWG stranded copper
- Number of Pairs: 4
- Insulation Material: Polypropylene
- Shielding: Foil + 80% braid
- Jacket Material: PVC, oil-resistant, black, 0.3 mm thickness
- Outer Diameter: 65 mm
- Max Elongation at Break: Conductors 10%, Insulation 100%, Jacket 100%
- Tensile Strength of Jacket: 15 MPa
- Impedance: 100 +/- 15 Ohm
- Capacitance: 1.6 pF/m to 156 pF/m
- Max Voltage: 450 VDC, 300 VAC
- Temperature Range: -40°C to +80°C (operating and storage)
- Minimum Bend Radius: 35 mm
- Max Puling Tension: 80 N
- Standards: ISO/IEC 11801, EN 5073, UL AWM 2464
- Compliance: RoHS, CPR Euroclass Eca, ANSI/TIA-568-B.2-1
- Flammability: IEC 60332-1-2
- Applicable Environments: Indoor, Euroclass Eca
Buy the Buy Belden DataTuff Ethernet Cat 5e Part Number 74002E01305 Online
Order the Belden DataTuff Ethernet Cat 5e cable online today for reliable, high-speed data transfer in industrial settings. Featuring 26 AWG stranded copper conductors, foil and braid shielding, and a durable PVC jacket, this cable supports 1 Gb/s Ethernet connections. Its compliance with industry standards ensures top performance in indoor environments, with excellent resistance to oil and temperature extremes. Fast, dependable, and designed for long-lasting durability, this cable is ideal for industrial networking applications, ensuring your system stays connected securely and efficiently.
Get Belden 74002E01305 today—designed for high-speed, durable industrial Ethernet networking with superior shielding and excellent temperature tolerance.
Frequently Asked Questions
Where can I buy BELDEN 74002E01305?
You can click on the BUY or RFQ button to purchase 74002E01305 from an authorized BELDEN distributor.
How do I troubleshoot issues or seek technical support for part 74002E01305?
You can download the 74002E01305 datasheet or visit the BELDEN website for support.
Who is the manufacturer of 74002E01305?
BELDEN
