BELDEN 8074 High-Temperature Signal Wire
The 8074 hook-up wire features a 16 AWG solid bare copper conductor insulated with Poly-Thermaleze®, a cross-linked, modified polyester base coat, topped with an amide-imide polymer. Rated for 200°C, it provides excellent solvent and mechanical abuse resistance, ideal for high-temperature environments such as industrial, automotive, military, and aerospace applications. With a nominal DC resistance of 4 ohms per 1000 feet at 20°C, it is suitable for computers, signal processing, lighting, motor control, HVAC, and electronic equipment, ensuring durability and reliable electrical performance.
BELDEN 8074 High-Temperature Signal Wire Specifications:
- Conductor: 16 AWG solid bare copper
- Insulation Material: Poly-Thermaleze® cross-linked polyester with amide-imide coating
- Rated Temperature: 200°C
- Insulation Thickness Increase: minimum 0.003 inches
- Overall Diameter: 0.545 inches
- Bulk Cable Weight: 8 lbs/1000 ft
- Length: approximately 126 ft
- Turns per Linear Inch: 166
- Turns per Square Inch: 346
- Nominal DC Resistance: 4 ohms per 1000 ft at 20°C
- Breakdown Voltage: ≥6000 volts at breakdown
- Applicable Standards & Environmental Compliance: RoHS, ELV, WEEE, BFR, Prop 65, MIL Spec Class 200, Type K2, NEMA-MW.35-C
- Mechanical Characteristics: Suitable for high-abuse environments
- Electrical Characteristics: High breakdown voltage, high-temperature performance
Buy the Belden Series 8074 Hook-up Wire: 16 AWG, 200°C Rated
Order the Belden 8074 hook-up wire online now to ensure reliable connections in high-temperature environments. This durable, solvent-resistant wire with PolytThermaleze® insulation is perfect for industrial, automotive, and aerospace applications. Its robust construction withstands mechanical abuse and electrical stress, making it ideal for demanding applications. With a temperature rating of 200°C, it guarantees performance in extreme conditions. Purchase online today for fast delivery, competitive pricing, and the quality assurance you need for your electronics, control systems, or HVAC projects.
Get Belden 8074 today—built for high-temperature durability and superior resistance for demanding industrial and aerospace applications.
Frequently Asked Questions
Where can I buy BELDEN 8074?
You can click on the BUY or RFQ button to purchase 8074 from an authorized BELDEN distributor.
How do I troubleshoot issues or seek technical support for part 8074?
You can download the 8074 datasheet or visit the BELDEN website for support.
Who is the manufacturer of 8074?
BELDEN
