BELDEN 832650091000 50 Ohm Coaxial Cable
This coaxial cable features a stranded 30 AWG silver-plated copper-covered steel conductor with TFE/PTFE insulation and a white FEP jacket. It includes a silver-plated copper braid shield with 95% coverage, designed for high-frequency signal transmission in communications and networking. The cable has a nominal impedance of 50 Ohms, a maximum operating temperature of 200°C, and a minimum bend radius suitable for flexible applications. Its rugged construction supports a pull tension of 12 lbs, making it ideal for demanding environments and secure installations.
BELDEN 832650091000 50 Ohm Coaxial Cable Specifications:
- Conductor Material: Silver-plated copper-covered steel
- Conductor Size: 30 AWG (0.012 inch)
- Insulation Material: TFE (Teflon®)
- Outer Shield: Silver-plated copper braid (95% coverage)
- Outer Jacket Material: FEP (Fluorinated Ethylene Propylene)
- Nominal Diameter: 0.071 inch
- Impedance: 50 Ohms
- Velocity of Propagation: approximately 69.5%
- Maximum Operating Temperature: 200°C
- Min. Bend Radius: Not specified but suitable for flexible routing
- Pulling Tension: Up to 12 lbs
- Weight: 5 lbs per 1000 ft
- DC Resistance Conductor: 244 Ω/1000 ft at 20°C
- Shield Resistance: 14.6 Ω/1000 ft
- Applicable Standards: MILSPEC A7, MI79G-RGI78, UL 1637
- Compliance: RoHS compliant, ELV, WEEE, Prop 65
Buy the Belden Series 83265 Coaxial Cable: 50 Ohm Coax
Purchase the Belden 83265 50 Ohm coaxial cable online today. Engineered for reliable signal transmission in communications and networking applications, this cable features a silver-plated copper conductor with TFE insulation and a durable FEP jacket. Its flexible design, high resistance to temperature extremes, and shielding make it suitable for demanding environments. With a maximum operating temperature of 200°C, a pull tension of 12 lbs, and low resistance, this cable ensures optimal performance and long-lasting durability. Order now for fast delivery and seamless setup.
Get Belden 83265 coaxial cable today—designed for high-frequency transmission, durability, and versatile installation in demanding environments.
Frequently Asked Questions
Where can I buy BELDEN 832650091000?
You can click on the BUY or RFQ button to purchase 832650091000 from an authorized BELDEN distributor.
How do I troubleshoot issues or seek technical support for part 832650091000?
You can download the 832650091000 datasheet or visit the BELDEN website for support.
Who is the manufacturer of 832650091000?
BELDEN
