BELDEN A0266827 Datasheet & Stock

The Belden A0266827 is a QCBIX5A 25-pair (5 x 5 pair) BIX multiplying connector designed to generate multiple outputs from a single input. Its construction is similar to BIX distribution connectors, with the key difference of bridged IDC clips—comprising 10 sets of bridged clips (5 each)—allowing multiple jumper connections to the same equipment. Ideal for equipment terminations in telecommunications rooms, this connector features a robust, installer-friendly design that reduces installation costs and space requirements. It has marked edges for easy wire pairing, built-in pair splitters for straightforward wire insertion, and a fully enclosed plastic housing to prevent injuries and protect connections. The connector snaps into BIX mounts for quick installation and removal, offers modular flexibility, and is constructed from fire-retardant beige thermoplastic meeting UL94V-0 standards. Made of copper alloy with tin plating over nickel IDC clips, it supports a maximum current of 1.5A. Suitable for industrial, communication, and networking applications.

View A0266827Datasheet [pdf]
