BELDEN C601109010 Ethernet Patch Cord
The Belden CAT6+ Patch Cord is a 7-foot, blue, bonded-pair, solid 24 AWG cable designed for high-performance Ethernet networks. Compliant with TIA Category 6, ISO Class E, and 1000BASE-T standards, it features a riser-rated UL 1666 flame rating, UL 1863 safety listing, and is RoHS compliant. The cable has a nominal overall diameter of 0.228 inches, with polyolefin insulation and a translucent boot. Suitable for indoor use, it supports reliable data transmission with dielectric strength of 1,000 V RMS and insulation resistance of 500 M-Ohm, making it ideal for network connections and data infrastructure.
BELDEN C601109010 Ethernet Patch Cord Specifications:
- Overall Diameter: 0.228 in.
- Conductor: 24 AWG solid copper
- Insulation Material: Polyolefin
- Outer Jacket Material: Polyolefin
- Jacket Color: Blue
- Wiring Scheme: T568A/B
- Flammability: UL 1666 Riser rated
- Safety Listing: UL 1863
- RoHS Compliance: Yes (2002/95/EC)
- Operating Temperature Range: -10°C to +60°C
- Installation Temperature Range: -10°C to +45°C
- Max Pull Tension: 25 lbs.
- Min Bend Radius: 1.04 in.
- Dielectric Strength: 1,000 V RMS @ 60 Hz
- Insulation Resistance: 500 M-Ohm Min
- Performance Standards: TIA 568-C.2, IEC 60603-7, FCC Part 68
- Cable Length: 7 ft
- Weight: 0.060 lbs.
- Labeling: Belden Part Number, Performance, Wiring Scheme, Length
Buy the Belden Series CAT6+ Ethernet Cable: C601106007
Enhance your network reliability with the Belden Series CAT6+ Ethernet Patch Cord. This 7-foot, blue bonded-pair cable is designed for high-speed data transmission, compliant with TIA Category 6 standards. Featuring UL Riser rating, RoHS compliance, and durable polyolefin insulation, it ensures safe, efficient connections for indoor networking. Ideal for data centers, offices, or network installations, this cord offers easy installation, robust performance, and long-lasting durability. Order online today to improve your infrastructure with high-quality, dependable cabling solutions.
Order your Belden Series C601106007 blue CAT6+ patch cord today and give your network the dependable, high-performance connection it deserves.
