Bourns 3214W1202E Trimmer Potentiometer
The 3214W1202E is a sealed, surface-mount trimmer potentiometer designed for precision adjustment in electronic circuits. Featuring a 4 mm square package, it complies with RoHS standards and meets industry standards for halogen-free components. Suitable for automated assembly, it offers excellent environmental resistance, including humidity, vibration, and thermal shock capabilities. With a wiper torque of a maximum of 180 g-cm, this trimmer is ideal for fine-tuning applications requiring reliable long-term performance and sturdy construction in industrial and consumer electronics.
Bourns 3214W1202E Trimmer Potentiometer Specifications:
- Package Size: 4 mm square surface-mount
- Material: Cermet, epoxy sealed
- Resistance Range: 10 ohms to 2 megaohms
- Resistance Tolerance: ±10%
- Insulation Resistance: 100 megohms min at 500 VDC
- Dielectric Strength: 600 VAC for 1 minute
- Temperature Range: -55°C to +150°C
- Temperature Coefficient: ±100 ppm/°C
- Power Rating: 85°C, up to 0.05 W (at 85°C)
- Vibration: 20 GTRS±1%, VRS±1%
- Shock Resistance: 100 GTRS±1%
- Humidity: MIL-STD 202 Method 106 compliance
- Rotational Cycling: 200 cycles with TRS ≤3%
- Load Life: 1000 hours at rated power, TRS ≤3%
- Flammability: UL94VO compliance
- Mechanical Torque: Max 180 g-cm
- Marking: Manufacturer's code, resistance, date
- Solderability: MIL-STD-202, Method 208
- Tape and Reel Packaging: Embossed tape designator E or 6 for automated placement
- RoHS Compliant, Halogen Free, Meets industry standards for environmental safety
Buy the Buy Bourns Trimmer Potentiometer Part Number 3214W1202E Online
Order the Bourns 3214W1202E trimmer potentiometer online today for your electronic adjustment needs. Designed for precision, this sealed, RoHS compliant component ensures reliable performance and easy assembly in industrial and consumer electronics. With a compact 4 mm square package, it offers excellent environmental resistance including humidity, vibration, and thermal shock. Its high insulation resistance and stability over temperature make it ideal for long-term use. Purchase now to enhance your project’s durability and precision with a trusted, industry-standard trimming potentiometer.
Get Bourns 3214W1202E today—built for precision adjustment and long-lasting durability in electronic circuit tuning.
Frequently Asked Questions
Where can I buy Bourns 3214W1202E?
You can click on the BUY or RFQ button to purchase 3214W1202E from an authorized Bourns distributor.
How do I troubleshoot issues or seek technical support for part 3214W1202E?
You can download the 3214W1202E datasheet or visit the Bourns website for support.
Who is the manufacturer of 3214W1202E?
Bourns
