Bourns 3224J1503E Surface Mount Trimmer
The 3224J1503E is a surface-mount 4 mm square trimmer potentiometer featuring a sealed, halogen-free design with RoHS compliance. Suitable for precise resistance adjustments in electronics and industrial applications, it offers high stability, a resistance range from 1.10 ohms to 2 megohms, and a temperature rating up to +150°C. Its compact size, top and side adjust styles, and robust construction make it ideal for applications requiring reliable calibration, minimal current variation, and resistance tolerance within 8%. It complies with industry standards, including EIA/EIAJ/IPC/VECI specifications, with an easy pick-and-place fit for manufacturing efficiency.
Bourns 3224J1503E Surface Mount Trimmer Specifications:
- Resistance Range: 1.10 to 2 megohm
- Resistance Tolerance: ±8%
- Resistance Code: From 10Ω (Code 100) to 2MΩ (Code 202)
- Temperature Range: -55°C to +150°C
- Power Rating: 0.1W at 85°C
- Voltage Rating: 300V max
- Adjustment Slots: Top and side adjustment styles
- Package: Surface Mount 4 mm square
- Material: Sealed, halogen-free, RoHS compliant
- Dimensions: 4 mm square footprint, height approximately 2.00 mm
- Resistance Resolution: Essentially infinite
- Insulation Resistance: 400 Megohms min.
- Capacitance: Not specified
- Environmental Resistance: Meets MIL-STD-202 Method 106, thermal shock, and rotational cycling tests
- Compliance: RoHS Directive 2002/95/EC, industry-standard halogen-free
Buy the Buy Industry-Standard Surface Mount Trimmer Part Number 3224J1503E Online
Purchase the Bourns 3224J1503E surface mount 4 mm square sealed trimmer potentiometer online today. Designed for high stability, precise resistance tuning, and reliable performance up to +150°C, this industry-standard component features halogen-free materials, RoHS compliance, and versatile adjustment styles. Ideal for calibration in industrial electronics, automation systems, and consumer devices, it offers a resistance range from 1.10 ohms to 2 megohms, with easy pick-and-place packaging, ensuring efficient manufacturing and durability in demanding environments. Get yours now for dependable, accurate resistance control.
Buy Bourns 3224J1503E now and experience unmatched reliability and precise resistance adjustments for industrial and electronics applications.
Frequently Asked Questions
Where can I buy Bourns 3224J1503E?
You can click on the BUY or RFQ button to purchase 3224J1503E from an authorized Bourns distributor.
How do I troubleshoot issues or seek technical support for part 3224J1503E?
You can download the 3224J1503E datasheet or visit the Bourns website for support.
Who is the manufacturer of 3224J1503E?
Bourns
