Bourns 3250W1501 Hook Up Wire
The Bourns 3250W-1-501 is a versatile hook-up wire suitable for a wide range of applications including internal wiring for appliances, electronics, and instrumentation. Its tinned copper conductor provides excellent conductivity, while the PVC insulation offers reliable electrical insulation and protection against abrasion. The wire is RoHS compliant, meeting environmental standards. Available in multiple colors, it simplifies identification and organization in complex wiring systems. It is ideal for applications requiring a durable and reliable wire solution.
Bourns 3250W1501 Hook Up Wire Specifications:
- Conductor: 24 (7/32) AWG Tinned Copper
- Insulation: 0.010" Wall, Nom. PVC
- Overall Diameter: 0.044+/- 0.002 inch
- Temperature Range: -10 to 80°C
- Bend Radius: 10X Cable Diameter
- Pull Tension: 3.5 Lbs, Maximum
- Voltage Rating: 300 VRMS
- Inductance: 0.05 µH/ft, Nominal
- Conductor DCR: 25 Ω/1000ft @20°C, Nominal
- UL Style: AWM 1061
- CSA Rating: AWM I A/B
- Colors: WHITE, BLACK, RED, GREEN, YELLOW, BLUE, BROWN, ORANGE, SLATE, VIOLET, PINK
- RoHS Compliant: Yes
- REACH Compliant: Yes
Buy the 3250W-1-501 BOURNS Hook Up Wire | myMectronic
Securely purchase the Bourns 3250W-1-501 hook-up wire online for your industrial needs.
Buy Now
Frequently Asked Questions
Where can I buy Bourns 3250W1501?
You can click on the BUY or RFQ button to purchase 3250W1501 from an authorized Bourns distributor.
How do I troubleshoot issues or seek technical support for part 3250W1501?
You can download the 3250W1501 datasheet or visit the Bourns website for support.
Who is the manufacturer of 3250W1501?
Bourns
