Bourns 3386F1202LF Trimmer Potentiometer
The 3386F1202LF is a precision, sealed, single-turn cermet trimmer potentiometer designed for industrial applications. It features a 3/8 inch square form factor with adjustable top or side models, available with a knob for finger adjustment, extended shaft, or cross-slot rotor. Suitable for trimming and calibration tasks, it offers a resistance range from 10 ohms to 2 megohms, with RoHS compliance, a power rating of 0.5 watt at 70°C, and a temperature range from -55°C to +125°C. Ideal for control, adjustment, and automation systems requiring high reliability.
Bourns 3386F1202LF Trimmer Potentiometer Specifications:
- Resistance Range: 10 ohms to 2 megaohms
- Power Rating: 0.5 watt @ 70°C
- Temperature Range: -55°C to +125°C
- Resistance Tolerance: ±10% (standard), tighter options available
- Sealed enclosure for industrial use, RoHS compliant
- Adjustment Types: Top and side adjust, with knob, extended shaft, cross-slot rotor options
- Dimensions: 3/8 inch square, with models featuring adjustable top or side configurations
- Environmental: Vibration 30 G, Shock 100 G, Humidity IEC-STD-202 Method 103
- Insulation Resistance: 1000 megohms min.
- Dielectric Strength: 70,000 feet altitude, standard test conditions
- Construction: RoHS compliant, UL 94V-0 flammability rating
Buy the Bourns 3386F1202LF – Reliable Trimmer for Industrial Applications
Purchase Bourns 3386F1202LF now for accurate and reliable adjustment in industrial settings. This sealed, RoHS-compliant trimmer potentiometer offers a resistance range from 10 ohms to 2 megaohms, with options for top or side adjustment, including a knob for finger tuning. Its rugged construction ensures long-term durability in challenging environments, making it ideal for calibration, control, and automation systems. Order online today and experience precise, dependable performance for your industrial applications with fast delivery and excellent customer support.
Get Bourns 3386F1202LF today—built for precision, durability, and dependable performance in industrial calibration and control tasks.
Frequently Asked Questions
Where can I buy Bourns 3386F1202LF?
You can click on the BUY or RFQ button to purchase 3386F1202LF from an authorized Bourns distributor.
How do I troubleshoot issues or seek technical support for part 3386F1202LF?
You can download the 3386F1202LF datasheet or visit the Bourns website for support.
Who is the manufacturer of 3386F1202LF?
Bourns
