Bourns 3386P1203LF Square Trimming Potentiometer
The Bourns 3386 series trimming potentiometers are versatile components used for precise adjustment in a wide range of industrial applications. These potentiometers offer a compact design, robust construction, and a broad resistance range from 10 ohms to 2 megohms. They are available in various configurations including top and side adjust types, extended shafts, and cross-slot rotors to meet specific application requirements. The Bourns 3386P-1-203LF model is RoHS compliant and designed for reliable performance in demanding environments.
Bourns 3386P1203LF Square Trimming Potentiometer Specifications:
- Resistance Range: 10 ohms to 2 megohms
- Resistance Tolerance: ±10 % std. (.030)
- Absolute Minimum Resistance: 2 ohms max.
- Contact Resistance Variation: 2 % or 3 ohms max.
- Adjustability: Infinite
- Voltage Divider: ±0.05 %
- Resolution: Infinite
- Insulation Resistance: 500 vdc. 1,000 megohms min.
- Dielectric Strength: 900 vac (Sea Level), 350 vac (70,000 Feet)
- Adjustment Angle: 280 ° nom.
- Power Rating: 0.5 watt (85 °C), 0.1 watt (125 °C)
- Temperature Range: -55 °C to +125 °C
- Temperature Coefficient: ±100 ppm/°C
- Seal Test: 85 °C Fluorinert
- Humidity: MIL-STD-202 Method 103 96 hours
- Vibration: 30 G (1 % ΔTR, 1 % ΔVR)
- Load LifeShock: 100 G (1 % ΔTR; 1 % ΔVR)
- Rotational Life: 200 cycles
- Mechanical Angle: 310 ° nom.
- Torque: 5.0 oz-in. max.
- Stop Strength: 15.0 oz -in. min.
- Terminals: Solderable pins
- Weight: 0.03 oz
- Marking: Manufacturer’s trademark, resistance code, wiring diagram, date code, manufacturer’s model number
- Flammability: U.L. 94V-0
