Bourns 3500S2104L Micro-DIP Rotary Switch
The Bourns 3500 Series Micro-DIP rotary switch is a versatile and compact solution for various applications requiring rotary switching functionality. Its low-profile design and sealed construction make it ideal for automated manufacturing processes and harsh environments. The switch features direct decimal to binary conversion, simplifying the addressing of PROM’s or setting microprocessor-controlled devices. Offered in multiple configurations, the 3500 Series provides design flexibility and is backed by a lifetime warranty. It is lead-free and fully RoHS compliant, ensuring environmental responsibility.
Bourns 3500S2104L Micro-DIP Rotary Switch Specifications:
- No. of Switching Positions: 8, 10, 16
- Life: 20,000 Detents at +250C
- Rotational Torque (Initial): 1.0-4.5 Inch/Ounces
- Terminal Strength: Pull 3 Pounds, Push 3 Pounds, for 15 Seconds
- Minimum Switching Current: 1µA
- Minimum Switching Voltage: 30 mVDC
- Maximum Electrical Current, Non-Switching: 1A
- Maximum Rated Load, Switching: 100 mA at 28 VDC Resistive
- Contact Resistance (Initial): 100 mΩ Maximum
- Insulation Resistance: 1,000 MΩ Minimum At 100 VDC
- Dielectric Withstanding Voltage: 250 VAC (RMS)
- Operating Temperature: -650C To +850C
- Storage Temperature: -650C To +1250C
- Vibration: 15g, 10 to 2,000 Hz, Method 204, Condition B of Mil-Std 202
- Moisture Resistance: Method 106, Mil-Std 202, 50 VDC Polarizing Voltage
- Seal: Top: O-Ring, Bottom: Epoxy
- Solderability: Method 208 of Mil-Std 202, 95% Coverage
- Solvent Resistance: Method 215 of Mil-Std 202
- Humidity: Method 103B of Mil-Std 202, Test Condition A, 50 VDC Polarizing Voltage
- Housing and Base: Glass Reinforced High Temperature 4/6 Nylon, UL 94 V0
- Rotor: Glass Reinforced 6/6 Nylon UL 94 V0
- O-Ring: Silicon Rubber
- Contact: Copper Alloy Base, Gold Over Nickel Plate
- Terminal: Matte Tin With Whisker Inhibitors Over Nickel Plate
- Weight: 0.03 Oz (.86G)
- Knobs Type B: ABS, UL 94 V0 (Black)
- Knobs Type K: Glass Reinforced Polyester, 94 V0 (White)
- Knobs Type V: Glass Reinforced 6/6 Nylon, 94 V0 (Black)
Buy the 3500S-2-104L BOURNS Micro-DIP Rotary Switch | myMectronic
Purchase the Bourns 3500S-2-104L Micro-DIP Rotary Switch securely and conveniently online.
Buy Now
Frequently Asked Questions
Where can I buy Bourns 3500S2104L?
You can click on the BUY or RFQ button to purchase 3500S2104L from an authorized Bourns distributor.
How do I troubleshoot issues or seek technical support for part 3500S2104L?
You can download the 3500S2104L datasheet or visit the Bourns website for support.
Who is the manufacturer of 3500S2104L?
Bourns
