Bourns 4306R101103LF Thick Film Molded SIP
Bourns 4306R-101-103LF is a thick film molded SIP (Single In-line Package) resistor network designed for a variety of applications including DRAM, SCSI, and R/2R ladder networks. The low profile design ensures compatibility with DIPs and automatic insertion equipment. Available in RoHS compliant versions, these resistors offer superior package integrity and precise resistance values. They are ideal for applications requiring multiple resistors in a compact form factor, providing a reliable and space-saving solution for circuit design.
Bourns 4306R101103LF Thick Film Molded SIP Specifications:
- Resistance Range: 10 ohms to 10 megohms
- Maximum Operating Voltage: 100 V
- Temperature Coefficient of Resistance: ±100 ppm/°C (below 50 Ω), ±250 ppm/°C (above 2.2 megohms)
- TCR Tracking: 50 ppm/°C
- Resistor Tolerance: See circuits
- Operating Temperature: -55 °C to +125 °C
- Power Rating: Derate to zero power from +70 °C to +125 °C
- Insulation Resistance: 10,000 megohms minimum
- Dielectric Withstanding Voltage: 200 VRMS
- Flammability: Conforms to UL94V-0
- Lead Frame Material: Copper, solder coated
- Body Material: Novolac epoxy
- Power Rating (4306R): 0.75 watts
- Power Rating (4308R): 1.00 watts
- Power Rating (4309R): 1.13 watts
- Power Rating (4310R): 1.25 watts
Buy the 4306R-101-103LF BOURNS Thick Film Molded SIP | myMectronic
Purchase the Bourns 4306R-101-103LF resistor network securely and efficiently online.
Buy Now
Frequently Asked Questions
Where can I buy Bourns 4306R101103LF?
You can click on the BUY or RFQ button to purchase 4306R101103LF from an authorized Bourns distributor.
How do I troubleshoot issues or seek technical support for part 4306R101103LF?
You can download the 4306R101103LF datasheet or visit the Bourns website for support.
Who is the manufacturer of 4306R101103LF?
Bourns
