Bourns 4605X101223LF Thick Film Conformal SIP Resistor
The Bourns 4605X-101-223LF is a thick film conformal SIP resistor designed for a wide range of applications requiring compact and reliable resistance solutions. Featuring a low profile compatible with DIPs, this resistor is RoHS compliant and offers permanent identification through contrasting background marking. Available in various pin packages and configurations (bussed, isolated, dual terminator), it provides design flexibility for applications such as DRAM, dual terminator resistor networks, R/2R ladder networks, and SCSI applications. The resistor's resistance range spans from 10 ohms to 10 megohms, with various tolerance options to meet specific circuit requirements.
Bourns 4605X101223LF Thick Film Conformal SIP Resistor Specifications:
- Resistance Range: 10 ohms to 10 megohms
- Maximum Operating Voltage: 100 V
- Temperature Coefficient of Resistance: ±100 ppm/°C (below 50 Ω), ±250 ppm/°C (above 2.2 megohms)
- Resistance Tolerance: See circuits
- Insulation Resistance: 10,000 megohms minimum
- Dielectric Withstanding Voltage: 200 VRMS
- Operating Temperature: -55 °C to +125 °C
- Short Time Overload: ±0.25 %
- Load Life: ±1.00 %
- Moisture Resistance: ±0.50 %
- Resistance to Soldering Heat: ±0.50 %
- Terminal Strength: ±0.25 %
- Thermal Shock: ±0.25 %
- Flammability: Conforms to UL94V-0
- Body Material: Epoxy resin
- Standard Packaging: Bulk, Ammo-pak available
- Maximum package length: 2.54mm (.100") times the number of pins, less .005mm (.002")
