Bourns 4606X101682LF Conformal SIP Resistor Network
The Bourns 4606X-101-682LF is a conformal SIP (Single In-line Package) resistor network designed for a variety of electronic applications. Its low profile makes it compatible with DIPs, and it offers a wide assortment of pin packages for enhanced design flexibility. The network is RoHS compliant and features permanent identification through contrasting background marking. Common applications include DRAM networks, SCSI applications, and R/2R ladder networks. It's available in bussed, isolated, and dual terminator configurations to meet diverse circuit requirements.
Bourns 4606X101682LF Conformal SIP Resistor Network Specifications:
- Resistance Range: 10 ohms to 10 megohms
- Maximum Operating Voltage: 100 V
- Temperature Coefficient of Resistance: ±100 ppm/°C (below 50 Ω), ±250 ppm/°C (above 2.2 megohms)
- Resistance Tolerance: See circuits
- Insulation Resistance: 10,000 megohms minimum
- Dielectric Withstanding Voltage: 200 VRMS
- Operating Temperature: -55 °C to +125 °C
- Short Time Overload: ±0.25 %
- Load Life: ±1.00 %
- Moisture Resistance: ±0.50 %
- Resistance to Soldering Heat: ±0.50 %
- Terminal Strength: ±0.25 %
- Thermal Shock: ±0.25 %
- Flammability: Conforms to UL94V-0
- Body Material: Epoxy resin
- Standard Packaging: Bulk, Ammo-pak available
- Model: 46 = Conformal SIP
- Physical Configuration: X = Thick Film Low Profile
- Electrical Configuration: - 101 = Bussed, - 102 = Isolated, - 104 = Dual Terminator
- Marking: Permanent identification on contrasting background
- Pin Count: 4 to 14
- Maximum Package Length: 2.54mm (.100") times the number of pins, less .005mm (.002")
- Terminal Centerline to Centerline Measurements: Made at point of emergence of the lead from the body
- Governing Dimensions: Metric
- Resistance Code: First 2 digits are significant, Third digit represents the number of zeros to follow
Buy the 4606X-101-682LF BOURNS Conformal SIP Resistor Network | myMectronic
Purchase the Bourns 4606X-101-682LF Conformal SIP Resistor Network securely and reliably online.
Buy Now
Frequently Asked Questions
Where can I buy Bourns 4606X101682LF?
You can click on the BUY or RFQ button to purchase 4606X101682LF from an authorized Bourns distributor.
How do I troubleshoot issues or seek technical support for part 4606X101682LF?
You can download the 4606X101682LF datasheet or visit the Bourns website for support.
Who is the manufacturer of 4606X101682LF?
Bourns
