Bourns 4606X102222LF Resistor Network
The 4606X Series resistor network features a low-profile, conformal thick film design ideal for compact electronic assemblies. It incorporates multiple resistors of fixed values interconnected in various configurations, including bussed, isolated, and dual terminator circuits. Suitable for applications requiring precise, stable resistance with low TCR tracking of 50 ppm/°C, these networks are RoHS compliant and compatible with rosin flux cleaning processes. Packaging options include bulk and ammo-pak, ensuring versatile integration into manufacturing processes while maintaining robust performance across temperatures from -55°C to +125°C.
Bourns 4606X102222LF Resistor Network Specifications:
- Resistance range: 10 ohms to 10 megohms
- Maximum operating voltage varies by configuration
- Temperature coefficient of resistance: +100 ppm/°C below 50°C, +250 ppm/°C above 2.2 megohms
- Resistance tolerance: typically +1% or +2%
- Insulation resistance: minimum 10,000 megohms
- Dielectric withstand voltage: 200 VRMS
- Operating temperature: -55°C to +125°C
- Physical dimensions vary with pin count, up to approximately 22.81 mm (0.898 inches) in length for 8-pin packages
- Body material: epoxy resin, flammability conforming to UL94V-0
- Terminations: Sn/Ag/Cu-plated, RoHS compliant
- Environmental tests per MIL-STD-202: includes moisture resistance, soldering heat, thermal shock, and overload testing
- Standard packaging: bulk, ammo-pak available
- Suitable for rosin flux and no clean flux processes
- Supported configurations include bussed (101), isolated (102), and dual terminator (104)
- Resistance coding: first digits significant, third digit zeros, tolerance code e.g., F for ±1%
Buy the Bourns Series 4606X Resistor Network: 4606X102222LF
Enhance your electronic assemblies with the Bourns Series 4606X resistor network, offering low-profile design, high thermal stability, and diverse configurations. Suitable for dense, precision circuits, these RoHS-compliant networks withstand temperature ranges from -55°C to +125°C. With options for bulk and ammo-pak packaging, they are ideal for manufacturing environments requiring reliable, stable resistors. The resistors feature resistance values from 10 ohms to 10 megohms, with TCR tracking of 50 ppm/°C, and are compatible with rosin flux cleaning processes, ensuring superior quality and performance.
Order your Bourns Series 4606X resistor network today and ensure reliable performance with low-profile, high-stability resistance solutions for your projects.
Frequently Asked Questions
Where can I buy Bourns 4606X102222LF?
You can click on the BUY or RFQ button to purchase 4606X102222LF from an authorized Bourns distributor.
How do I troubleshoot issues or seek technical support for part 4606X102222LF?
You can download the 4606X102222LF datasheet or visit the Bourns website for support.
Who is the manufacturer of 4606X102222LF?
Bourns
