Bourns 4610X101331LF Resistor Network
The 4600X Series Thick Film Conformal SIPs are high-reliability resistor networks designed for various electronic applications including dual terminators, bused, and isolated resistor configurations. Built with epoxy resin bodies and Sn/Ag/Cu-plated terminations, these RoHS-compliant packages offer wide resistance ranges from 10 ohms to 10 megohms, with tolerance options of ±1% or ±2%. Suitable for PCB mounting, they withstand environmental stresses like moisture, soldering heat, and thermal shock, making them ideal for circuit protection, signal conditioning, and complex resistor array applications.
Bourns 4610X101331LF Resistor Network Specifications:
- Resistance Range: 10 ohms to 10 megohms
- Maximum Operating Voltage: -200 VRMS dielectric withstanding voltage
- Temperature Coefficient of Resistance: +100 ppm/°C below 50°C, +250 ppm/°C above 2.2 megohms
- Resistor Tolerance: ±1% or ±2%
- Insulation Resistance: Minimum 10,000 megohms
- Environmental Testing: MIL-STD-202, including moisture resistance and soldering heat
- Body Material: Epoxy resin
- Flammability: UL94V-0 compliant
- Terminations: Sn/Ag/Cu-plated, RoHS compliant
- Operating Temperature Range: -55°C to +125°C
- Physical Dimensions: Length varies with pin count, typical lengths from 10.11mm to 30.43mm
- Packaging: Bulk and Ammo-pak available
- Configuration: Bussed, Isolated, Dual terminator options, with multiple pin counts
Buy the Bourns Series 4600X Resistor Network: 4610X101331LF
Discover the reliability and versatility of the Bourns Series 4600X resistor networks, designed for high-performance electronic applications. These resistor arrays support resistance values from 10 ohms to 10 megohms with tight tolerance options of ±1% or ±2%. Built with epoxy resin bodies and Sn/Ag/Cu terminations, they’re RoHS compliant and resistant to environmental stresses such as moisture, soldering heat, and thermal shocks. Ideal for PCB mounting, these resistor networks are perfect for complex resistor arrays, circuit protection, and signal conditioning, ensuring durability and stability in demanding conditions.
Order your Bourns Series 4600X resistor network today and enhance your circuit reliability with high-quality, RoHS-compliant solutions for your electronic projects.
Frequently Asked Questions
Where can I buy Bourns 4610X101331LF?
You can click on the BUY or RFQ button to purchase 4610X101331LF from an authorized Bourns distributor.
How do I troubleshoot issues or seek technical support for part 4610X101331LF?
You can download the 4610X101331LF datasheet or visit the Bourns website for support.
Who is the manufacturer of 4610X101331LF?
Bourns
