Bourns 4610X102101LF Thick Film Conformal SIP Resistor
Bourns 4610X-102-101LF thick film conformal SIP resistors are designed for applications requiring a compact and reliable resistor network. These resistors offer a low profile, making them compatible with DIPs, and are RoHS compliant. They feature permanent identification through contrasting background marking and are available in various pin packages to enhance design flexibility. The resistors are recommended for rosin flux and solvent clean processes, ensuring optimal performance and reliability in diverse industrial applications.
Bourns 4610X102101LF Thick Film Conformal SIP Resistor Specifications:
- Resistance Range: 10 ohms to 10 megohms
- Maximum Operating Voltage: 100 V
- Temperature Coefficient of Resistance: ±100 ppm/°C (below 50 Ω), ±250 ppm/°C (above 2.2 megohms)
- Resistance Tolerance: See circuits
- Insulation Resistance: 10,000 megohms minimum
- Dielectric Withstanding Voltage: 200 VRMS
- Operating Temperature: -55 °C to +125 °C
- Short Time Overload: ±0.25 %
- Load Life: ±1.00 %
- Moisture Resistance: ±0.50 %
- Resistance to Soldering Heat: ±0.50 %
- Terminal Strength: ±0.25 %
- Thermal Shock: ±0.25 %
- Flammability: Conforms to UL94V-0
- Body Material: Epoxy resin
- Standard Packaging: Bulk, Ammo-pak available
- Model: 46 = Conformal SIP
- Physical Configuration: X = Thick Film Low Profile
- Electrical Configuration: - 101 = Bussed, - 102 = Isolated, - 104 = Dual Terminator
- Marking: Permanent identification on contrasting background
- Pin Packages: Wide assortment for design flexibility
- Resistance Code: First 2 digits are significant, Third digit represents the number of zeros to follow
Buy the 4610X-102-101LF BOURNS Thick Film Conformal SIP Resistor | myMectronic
Securely purchase the Bourns 4610X-102-101LF resistor network online for reliable performance and fast delivery.
Buy Now
Frequently Asked Questions
Where can I buy Bourns 4610X102101LF?
You can click on the BUY or RFQ button to purchase 4610X102101LF from an authorized Bourns distributor.
How do I troubleshoot issues or seek technical support for part 4610X102101LF?
You can download the 4610X102101LF datasheet or visit the Bourns website for support.
Who is the manufacturer of 4610X102101LF?
Bourns
