Bourns 4610X102103LF Thick Film Conformal SIP Resistor
Bourns 4610X-102-103LF thick film conformal SIP resistors are designed for applications requiring a compact and reliable resistor network. These resistors offer a low profile, making them compatible with DIPs, and are RoHS compliant. They are available in a wide assortment of pin packages, enhancing design flexibility. The resistors feature permanent identification through contrasting background marking and are recommended for rosin flux and solvent clean processes. They are commonly used in DRAM applications, R/2R ladder networks, and SCSI applications.
Bourns 4610X102103LF Thick Film Conformal SIP Resistor Specifications:
- Resistance Range: 10 ohms to 10 megohms
- Maximum Operating Voltage: 100 V
- Temperature Coefficient of Resistance: ±100 ppm/°C (below 50 Ω), ±250 ppm/°C (above 2.2 megohms)
- Resistance Tolerance: See circuits
- Insulation Resistance: 10,000 megohms minimum
- Dielectric Withstanding Voltage: 200 VRMS
- Operating Temperature: -55 °C to +125 °C
- Short Time Overload: ±0.25 %
- Load Life: ±1.00 %
- Moisture Resistance: ±0.50 %
- Resistance to Soldering Heat: ±0.50 %
- Terminal Strength: ±0.25 %
- Thermal Shock: ±0.25 %
- Flammability: Conforms to UL94V-0
- Body Material: Epoxy resin
- Standard Packaging: Bulk, Ammo-pak available
- Model: 46 = Conformal SIP
- Physical Configuration: X = Thick Film Low Profile
- Electrical Configuration: - 101 = Bussed, - 102 = Isolated, - 104 = Dual Terminator
- Marking: Permanent identification on contrasting background
- Pin Count: 4 to 14
- Maximum Package Length: 2.54mm (.100") times the number of pins, less .005mm (.002")
- Governing Dimensions: Metric
- Terminal Centerline to Centerline Measurements: Made at point of emergence of the lead from the body
