Bourns 4610X102472LF Resistor Network
The Bourns 4600X series resistor networks are thick film, single inline package components designed for space-sensitive applications. They reduce board space, lower costs, and improve reliability by decreasing the component count. Suitable for use in computer, telephone, telecommunication testing, satellite, optical networking, and voice recognition equipment, these networks feature resistance values ranging from 10 ohms to 10 megaohms. They operate at up to 100V, with temperature coefficients of ±100 ppm/°C or ±250 ppm/°C, and can withstand temperatures from -55°C to +125°C. The low-profile design is compatible with DIP packages and offers a variety of pin configurations for flexible integration. It is recommended for use with rosin flux, solvent clean, or no-clean flux processes.
Bourns 4610X102472LF Resistor Network Specifications:
- Resistance Range: 10 ohms to 10 megaohms
- Maximum Operating Voltage: 100V
- Temperature Coefficient of Resistance: ±100 ppm/°C or ±250 ppm/°C
- Insulation Resistance: 10,000 megohms minimum
- Dielectric Withstanding Voltage: 200 VRMS
- Operating Temperature: -55°C to +125°C
- Flammability: Conforms to UL94V-0
- Body Material: Epoxy resin
- Package Power Ratings: 0.30 watt per resistor (typical at 70°C), derating applies
- Physical Dimensions: Varying pin counts with lengths from approx. 10.11 mm to 30.43 mm
- Environmental Tests: Meets MIL-STD-202, resistance to soldering heat, moisture resistance, thermal shock, short time overload, load life
- Termination: Sn/Ag/Cu-plated, RoHS compliant
Buy the Buy Bourns 4600X Series Resistor Network Part Number 4610X102472LF Online
Purchase the Bourns 4600X Series resistor network online today to upgrade your electronic projects with dependable, space-efficient, and high-precision components. These networks are ideal for telecommunication, satellite, optical networking, and voice recognition equipment, providing resistance from 10 ohms to 10 megaohms. They operate efficiently up to 100V and withstand temperatures from -55°C to +125°C. Compatible with various flux cleaning processes, they offer flexibility, durability, and ease of integration, ensuring your design's reliability and performance. Order now for fast delivery and seamless integration.
Order your Bourns 4600X Series resistor network today and enhance your electronic design with high-quality, space-saving, and reliable components.
Frequently Asked Questions
Where can I buy Bourns 4610X102472LF?
You can click on the BUY or RFQ button to purchase 4610X102472LF from an authorized Bourns distributor.
How do I troubleshoot issues or seek technical support for part 4610X102472LF?
You can download the 4610X102472LF datasheet or visit the Bourns website for support.
Who is the manufacturer of 4610X102472LF?
Bourns
