Bourns 70AAJ2F0 Modular Female Contact
The Bourns 70AAJ-2-F0 is a modular female connector designed for versatile applications requiring reliable connections. It boasts a 2.54mm pitch and is constructed with glass-reinforced thermoplastic for durability. Key features include halogen-free compliance, a high cycle life of 50,000 cycles, and twin hot contacts that facilitate symmetrical pad layouts. The connector is suitable for applications in industrial automation, instrumentation, and other electronic devices where robust and reliable connectivity is essential. Its modular design allows for flexible configuration and easy integration into various systems.
Bourns 70AAJ2F0 Modular Female Contact Specifications:
- Current Rating: 3 A/contact
- Voltage Rating: 60 V
- Contact Resistance: 30 mohms max.
- Dielectric Voltage: AC 500 V
- Insulating Resistance: 1000 Mohms min.
- Operating Temperature: -55 °C to 125 °C
- Mechanical Durability: 50,000 cycles min.
- Contact Resistance after 50,000 Cycles: 50 mΩ
- MSL: 1
- ESD Rating (HBM): 3B
- Terminal Style: SMT
- Number of Contacts: 2 through 6
- Gender: Female
- Options: Standard, Locating Pins
- Packaging Option: Tube (240/N pcs. or 240 contacts per tube)
- Halogen Free: <900 ppm Bromine, <900 ppm Chlorine, <1500 ppm total Bromine and Chlorine
- Pitch: 2.54 mm
- Contact Material: Copper alloy
- Contact Finish: 30 µ” min. Ni Contact Area, 30 µ” min. Au over Ni
- Insulator Material: Glass reinforced thermoplastic, UL 94V-0 rated, black
