Bourns CAT10220J4LF Chip Resistor Array
The Bourns CEVA UA chip resistor array features four isolated, high-reliability resistors in an 0804 package, suitable for precision applications. Resistant from 10 ohms to 1 megohm with a ±5% tolerance, it operates within -55°C to +125°C temperature range. With a power rating of 125 mW at 70°C, it includes features like RoHS compliance, a protective glass overcoat, and tin-plated terminations. Designed for automatic placement, it boasts a concave termination style and is packaged in tapes of 10,000 pieces for efficient manufacturing. Ideal for compact circuit designs requiring high accuracy and durability.
Bourns CAT10220J4LF Chip Resistor Array Specifications:
- Number of Elements: 4 (isolated)
- Resistance Range: 10 ohms to 1 megohm
- Resistance Tolerance: ±5%
- Operating Temperature Range: -55°C to +125°C
- Power Rating at 70°C: 125 mW
- Maximum Overload Voltage: 50V
- TCR: +250 ppm/°C
- Construction: Thick Film Resistive Element, Glass Overcoat
- Package Size: 0804 (2.00 x 1.00 mm)
- Terminations: Tin-plated (RoHS compliant), Concave style
- Packaging: Tape on plastic reel, 10,000 pieces
- Soldering Profile: 260°C peak, 20 seconds max
Buy the Bourns Series CEVA Chip Resistor Array: CAT10220J4LF
Purchase the Bourns CEVA CAT10220J4LF chip resistor array online today to ensure your electronic projects benefit from high accuracy, durability, and RoHS compliance. Designed with four isolated resistors in an 0804 package, it covers a resistance range from 10 ohms to 1 megohm, with ±5% tolerance. Operating in temperatures from -55°C to +125°C, it provides high reliability for demanding applications. The resistors feature a thick film element, glass overcoat, and tin-plated terminations, and are suitable for automated assembly in high-volume production. Secure yours now for optimal circuit performance.
Buy Bourns CEVA CAT10220J4LF resistor array now and experience unmatched reliability and performance for precision electronic circuits.
Frequently Asked Questions
Where can I buy Bourns CAT10220J4LF?
You can click on the BUY or RFQ button to purchase CAT10220J4LF from an authorized Bourns distributor.
How do I troubleshoot issues or seek technical support for part CAT10220J4LF?
You can download the CAT10220J4LF datasheet or visit the Bourns website for support.
Who is the manufacturer of CAT10220J4LF?
Bourns
