Bourns CRM1206JW1R0ELF High Power Thick Film Resistor
The CRM1206JW1R0ELF is a high-power thick film chip resistor designed for current sensing and power supply applications. Offering a power rating of 0.5W at 70°C, it features low resistance values, high reliability, and RoHS compliance. Suitable for current limiting and flyback snubber circuits, it provides stable electrical characteristics over a wide temperature range of -55°C to +155°C. Its compact 1206 package dimensions make it ideal for precision placement in various industrial and electronic applications where high power handling and thermal stability are critical.
Bourns CRM1206JW1R0ELF High Power Thick Film Resistor Specifications:
- Size: 1206 (3.20×1.60 mm)
- Power Rating: 0.5W at 70°C
- Resistance Range: 47 mΩ to 910 mΩ (±1%, E24 Series)
- Resistance Tolerance: ±1%, ±5%
- Temperature Coefficient: ±100 ppm/°C (typical)
- Operating Temperature Range: -55°C to +155°C
- Maximum Working Voltage: 200 V
- Insulation Resistance: >1000 megaohms
- Material: Thick film ceramic resistor
- RoHS Compliant
- Maximum Rated Current: 4A
- Thermal Shock Resistance: -55°C to +155°C, 6 cycles
- Pulse Load Capability: Refer to datasheet for detailed profile
- Packaging: 180 mm reel
Buy the BOURNS CRM1206 U+2013 Reliable High Power Resistor for Industrial Applications
Enhance your electronic projects with the BOURNS CRM1206 high power thick film resistor. Designed for accurate current sensing and power regulation, it ensures stable operation within a broad temperature range. Its compact 1206 size makes it ideal for space-constrained applications, providing reliable performance in power supplies, snubber circuits, and critical industrial systems. RoHS compliant, with a power rating of 0.5W at 70°C, this resistor is essential for high-current, high-reliability environments. Order online today for fast delivery and seamless integration into your designs.
Buy BOURNS CRM1206 now and experience unmatched reliability and performance in current sensing and power supply circuits.
Frequently Asked Questions
Where can I buy Bourns CRM1206JW1R0ELF?
You can click on the BUY or RFQ button to purchase CRM1206JW1R0ELF from an authorized Bourns distributor.
How do I troubleshoot issues or seek technical support for part CRM1206JW1R0ELF?
You can download the CRM1206JW1R0ELF datasheet or visit the Bourns website for support.
Who is the manufacturer of CRM1206JW1R0ELF?
Bourns
