Bourns PM370050RC Common Mode Choke
The Bourns PM3700 Series SMD common mode choke provides high current handling up to 7A, compact size, and RoHS compliance. Designed for filtering and noise suppression, it features low DCR, inductance values ranging from 0.2 mH to 20 mH, and operates across temperatures from -55°C to +125°C. Suitable for power supplies, signal filtering, and electromagnetic interference reduction in electronic circuits, these surface-mount components meet stringent quality standards, making them ideal for modern compact and high-performance electronic applications.
Bourns PM370050RC Common Mode Choke Specifications:
- Inductance Range: 0.2 mH to 20 mH
- Current Rating: up to 7 A
- DCR: 0.008 Ω to 0.25 Ω
- Operating Temperature: -55°C to +125°C
- Soldering Temperature: 245°C for 5 seconds max
- Leakage Inductance: 16 to 50 nH
- Frequency Range: 1-55 MHz to 4-40 MHz depending on model
- Material: Ferrite, polyester-coated copper, Sn-Ag-Cu alloy terminals
- Packaging: 200 pcs per reel
- Dimensions: Approximately 21.59 mm x 10.85 mm
- RoHS Compliant: Yes
Buy the Bourns Series PM3700 Common Mode Choke: PM370050RC
Order the Bourns PM3700 Series Common Mode Choke online today to enhance your electronic design with reliable noise filtering. These surface-mount components handle currents up to 7A, feature low DCR, and operate across a wide temperature range from -55°C to +125°C, ensuring high performance in power supplies and signal filtering. With RoHS compliance, compact dimensions, and robust construction, they are ideal for modern electronics requiring compactness, durability, and efficient electromagnetic interference suppression. Purchase now for optimized circuit performance.
Get Bourns PM370050RC today—built for precision and long-lasting durability in high-current filtering applications.
Frequently Asked Questions
Where can I buy Bourns PM370050RC?
You can click on the BUY or RFQ button to purchase PM370050RC from an authorized Bourns distributor.
How do I troubleshoot issues or seek technical support for part PM370050RC?
You can download the PM370050RC datasheet or visit the Bourns website for support.
Who is the manufacturer of PM370050RC?
Bourns
