Bourns PV175K4032R2 Voltage Suppressor
The PV Series is a range of low and medium voltage, plastic-encapsulated varistors designed for surge protection in electronic devices and circuits. These surface mount components are RoHS compliant with non-flammable UL 94 V-0 rated thermoplastic encapsulation, providing reliable transient voltage suppression. Available in models ranging from 11 to 300 Vrms, with maximum surge currents from 100 A to 1200 A. They are suitable for applications like power supplies, sensors, and distribution panels, offering easy soldering, tape and reel packaging, and robust mechanical and environmental resilience.
Bourns PV175K4032R2 Voltage Suppressor Specifications:
- Operating Voltage Range: DC 14 V to 385 V, AC 11 V to 300 V
- Surge Current: 100 A to 1200 A
- Transient Energy: 0.6 to 30 J
- Continuous Operating Temperature: -40°C to +85°C
- Thermoplastic Encapsulation: UL 94 V-0 rated, non-flammable
- Contacts: Tinned Copper Sheet
- Model Sizes Available: 3225 & 4032
- RoHS Compliant
- Soldering: Surface mount design with tape and reel packaging, compatible with reflow and wave soldering
- Certifications: UL 1449 recognized, agency recognition as per IEC and CECC standards
Buy the Bourns Series PV Varistors: Low & Medium Voltage Surge Protection PV175K4032R2
Order Bourns PV Series voltage suppressors online today to protect your electronic systems from voltage surges. These surface-mount varistors deliver high surge current capacity, RoHS compliance, and robust thermoplastic encapsulation for durable, reliable performance. Ideal for power supplies, sensors, and distribution panels, they are available in tape and reel packaging for convenient automated assembly. Enhance your project’s safety and reliability—buy now and experience unmatched surge protection with easy integration and proven durability.
Buy Bourns PV175K4032R2 varistors now and ensure reliable surge suppression with easy soldering and robust environmental compliance.
Frequently Asked Questions
Where can I buy Bourns PV175K4032R2?
You can click on the BUY or RFQ button to purchase PV175K4032R2 from an authorized Bourns distributor.
How do I troubleshoot issues or seek technical support for part PV175K4032R2?
You can download the PV175K4032R2 datasheet or visit the Bourns website for support.
Who is the manufacturer of PV175K4032R2?
Bourns
