Bourns SRP03104R7K Power Inductor
The shielded power inductors with metal alloy powder core and flat wire design are RoHS compliant and halogen free. They feature high saturation current, low buzz noise, and are suitable for high-frequency applications. Designed for efficient power management, these inductors operate within a temperature range of -40°C to +125°C, with a rated voltage of 50V and recommended layout for reliable performance. Their compact dimensions and robust construction make them ideal for switching power supplies and electronic circuits requiring high efficiency and low noise.
Bourns SRP03104R7K Power Inductor Specifications:
- Inductance: 0.47μH to 4.70μH
- Tolerance: ±10%
- Rated Voltage: 50V
- Operating Temperature: -40°C to +125°C
- Core Material: Metal alloy powder
- Wire Material: Enameled copper
- Terminal Finish: Sn
- Packaging: 4000 pcs per reel
- Soldering Peak Temperature: 260°C max
- Soldering Time Above 217°C: 60-150 sec
- Dimensions vary by model, typical height about 4.0 mm
- Moisture Sensitivity Level: 1
- RoHS compliant and halogen free
- Recommended layout for high reliability in power circuits
Buy the Bourns Series SRP Power Inductors: SRP0310-4R7K
Purchase the Bourns SRP0310-4R7K power inductor online today and enhance your electronic designs with high saturation current, low noise, and RoHS compliance. These shielded inductors feature flat wire technology for efficient power management, operate within -40°C to +125°C temperature range, and have a rated voltage of 50V. Perfect for switching power supplies and high-frequency applications, they come in a reel packaging of 4000 pcs, ensuring easy assembly and consistent performance in demanding electronic environments.
Buy Bourns SRP0310-4R7K now and experience unmatched reliability and performance in high-frequency power circuits.
Frequently Asked Questions
Where can I buy Bourns SRP03104R7K?
You can click on the BUY or RFQ button to purchase SRP03104R7K from an authorized Bourns distributor.
How do I troubleshoot issues or seek technical support for part SRP03104R7K?
You can download the SRP03104R7K datasheet or visit the Bourns website for support.
Who is the manufacturer of SRP03104R7K?
Bourns
