Bourns SRP03151R5K Shielded Inductor
The SRP0315-R5K is a high-performance shielded inductor featuring a metal alloy powder core, flat wire construction, high saturation current, and RoHS compliance. Designed for power management and filtering applications, it exhibits low buzz noise and operates efficiently at temperatures from -40°C to +125°C. Its compact size and robust construction make it suitable for high-density circuit designs, ensuring reliable performance in demanding environments. The component is packaged on a 3000-piece reel, ideal for automated assembly and mass production. This inductor supports a rated voltage of 50V and handles high current levels with minimal inductance drop.
Bourns SRP03151R5K Shielded Inductor Specifications:
- Core Material: Metal alloy powder
- Wire: Enameled copper
- Terminal Finish: Sn (tin)
- Inductance Values: 0.47 µH to 4.7 µH
- Rated Voltage: 50 V
- Operating Temperature Range: -40 °C to +125 °C
- Storage Temperature Range: -40 °C to +125 °C
- Moisture Sensitivity Level: 1
- Soldering Peak Temperature: 260 °C max with a maximum of 30 seconds above 217 °C
- Peak Temperature Time: 60-150 seconds
- Package: 3000 pcs/reel
- Dimensions: Compact size for high-density applications
- RoHS compliant and halogen free
- Includes recommended layout and general operating specifications
Buy the Bourns Series Shielded Inductor: SRP0315-R5K
Purchase the Bourns SRP0315-R5K shielded inductor online today and ensure high efficiency and durability in your power management circuits. With RoHS compliance and a robust metal alloy core, this compact component supports high saturation currents and operates reliably from -40°C to +125°C. Its flat wire construction reduces buzz noise, making it ideal for demanding environments. Packaged on a 3000-piece reel, it is perfect for automated assembly, ensuring fast delivery and consistent quality for your high-volume manufacturing needs.
Buy Bourns SRP0315-R5K inductor now and experience unmatched reliability and performance in power filtering applications.
Frequently Asked Questions
Where can I buy Bourns SRP03151R5K?
You can click on the BUY or RFQ button to purchase SRP03151R5K from an authorized Bourns distributor.
How do I troubleshoot issues or seek technical support for part SRP03151R5K?
You can download the SRP03151R5K datasheet or visit the Bourns website for support.
Who is the manufacturer of SRP03151R5K?
Bourns
