Bourns SRP0315R68K Shielded Inductor
The SRP0315R68K is a high-performance shielded inductor with a metal alloy powder core, designed for reliable power applications. It features high saturation current, low buzz noise, and flat wire construction, making it suitable for various electronic circuits. Compliant with RoHS and halogen-free standards, this component offers excellent electrical stability at 25°C with inductance values around 0.68 µH. It can operate from -40°C to +125°C, with a rated voltage of 50V and a moisture sensitivity level of 1, ensuring durability in demanding environments.
Bourns SRP0315R68K Shielded Inductor Specifications:
- Inductance: 0.68 µH ±10%
- Test Frequency: 100 kHz / 1V
- Max. Saturation Current: 8A
- Operating Temperature Range: -40°C to +125°C
- Rated Voltage: 50V
- Core Material: Metal alloy powder
- Wire Material: Enameled copper
- Terminal Finish: Sn
- Packaging: 3000 pcs per reel
- Peak Reflow Temperature: 260°C max
- Moisture Sensitivity Level: 1
- Certification: RoHS compliant, halogen free
- Dimensions: 15.2 x 15.2 mm, typical thickness 4.7 mm
- ESD Classification: N/A
Buy the Bourns Series SRP Inductor: 0.68 µH Shielded Inductor SRP0315R68K
Order the Bourns SRP0315R68K shielded inductor online today to ensure your power circuits are supported by a high-quality, RoHS-compliant component. Featuring a 0.68 µH inductance with high saturation current, this inductor is ideal for demanding applications. Its compact size, RoHS compliance, halogen-free construction, and reliable performance across a wide temperature range make it the perfect choice for engineers seeking durability and efficiency. Purchase now to leverage quick shipping and superior technical support for your electronic projects.
Buy Bourns SRP0315R68K high-performance inductor now and experience unmatched reliability and power stability for your electronic designs.
Frequently Asked Questions
Where can I buy Bourns SRP0315R68K?
You can click on the BUY or RFQ button to purchase SRP0315R68K from an authorized Bourns distributor.
How do I troubleshoot issues or seek technical support for part SRP0315R68K?
You can download the SRP0315R68K datasheet or visit the Bourns website for support.
Who is the manufacturer of SRP0315R68K?
Bourns
