Bourns SRP04102R2K Power Inductor
The SRP0410 series shielded power inductors feature a metal alloy powder core, high saturation current, and low buzz noise, suitable for high current applications. Designed with RoHS compliance and halogen-free materials, these flat wire inductors operate efficiently at temperatures from -40°C to +125°C and are rated for a maximum voltage of 50V. With dimensions approximately 4.10 mm in length, these inductors support various inductance options, making them ideal for power supplies, DC-DC converters, and filtering in high-performance electronics.
Bourns SRP04102R2K Power Inductor Specifications:
- Core Material: Metal alloy powder
- Inductance Range: 0.47 µH to 10 µH
- Rated Voltage: 50V
- Temperature Range: -40°C to +125°C
- Max. Peak Temperature: 260°C
- Dimensions: Approx. 4.10 mm length
- RoHS compliant and halogen free
- Saturation Current: up to 350 mA depending on model
- DCR (Dc Resistance): 24 to 29.5 mΩ
- Quality factor at 100 kHz: 10 to 20
- Packaging: 4000 pcs per reel
- Maximum current ratings vary with inductance value
- Peak Temperature: 260°C max. for soldering
- Moisture Sensitivity Level: 1
- ESD Classification: N/A
Buy the Bourns Series SRP0410 Shielded Power Inductors: SRP0410-R2K
Purchase the Bourns Series SRP0410 2R2K power inductor online today, perfect for high-current power supply circuits, DC-DC converters, and filtering applications. With a robust metal alloy powder core, low DCR, high saturation current, and RoHS compliance, this shielded inductor offers excellent performance across a wide temperature range from -40°C to +125°C. The flat wire design minimizes noise, ensuring reliable operation in demanding electronic environments. Ready for efficient assembly, this component supports various inductance needs with precise ratings, making it an ideal choice for engineers seeking durability and quality in power management and filtering solutions.
Order your Bourns Series SRP0410 2R2K shielded power inductor today and enhance your electronic designs with reliable, high-current inductance solutions.
Frequently Asked Questions
Where can I buy Bourns SRP04102R2K?
You can click on the BUY or RFQ button to purchase SRP04102R2K from an authorized Bourns distributor.
How do I troubleshoot issues or seek technical support for part SRP04102R2K?
You can download the SRP04102R2K datasheet or visit the Bourns website for support.
Who is the manufacturer of SRP04102R2K?
Bourns
