Bourns SRP05104R7K Inductor Module
The SRP0510-4R7K is a high-performance shielded inductor designed for automotive, industrial, and electronic applications. Featuring a metal alloy powder core, it provides high saturation current, low buzz noise, and RoHS compliance. Its compact dimensions and flat wire construction ensure reliable performance with an inductance of 4.7 µH, rated current of 5.0 A, and saturation current of 10.5 A at 100 kHz/1V. Suitable for power management circuits, it offers robust electrical characteristics, temperature range from -40°C to +125°C, and RoHS Halogen-Free certified materials for eco-friendly use.
Bourns SRP05104R7K Inductor Module Specifications:
- Inductance: 4.7 µH
- Test Frequency: 100 kHz/1V
- SRF: 290.0 MHz
- Dc Resistance: 0.24 Ω
- Irms: 5.0 A
- Isat: 10.5 A
- Temperature Range: -40°C to +125°C
- Material: Metal alloy powder core
- Wire: Enameled copper
- Finish: Sn
- Packaging: 4000 pcs per reel
- Peak Soldering Temperature: 260°C max
- Max. Peak Temperature Duration: 30 sec
- Moisture Sensitivity Level: Level 1
- RoHS compliance: Yes, halogen free
Buy the Bourns SRP0510-4R7K – Reliable Inductor for Industrial Applications
Discover the Bourns SRP0510-4R7K inductor, engineered for high reliability and efficiency in industrial, automotive, and power management circuits. Its high saturation current, RoHS compliance, and compact design make it ideal for demanding electronic applications. With a rated current of 5.0 A and saturation of 10.5 A at 100 kHz/1V, it offers excellent thermal stability from -40°C to +125°C. Purchase online today to ensure your electronic projects perform with optimal stability and durability, leveraging Bourns' trusted quality.
Get Bourns SRP0510-4R7K today—built for precision and long-lasting durability in power management and electronic circuits.
Frequently Asked Questions
Where can I buy Bourns SRP05104R7K?
You can click on the BUY or RFQ button to purchase SRP05104R7K from an authorized Bourns distributor.
How do I troubleshoot issues or seek technical support for part SRP05104R7K?
You can download the SRP05104R7K datasheet or visit the Bourns website for support.
Who is the manufacturer of SRP05104R7K?
Bourns
