Bourns SRP0520R68K Power Inductor
The Bourns SRP0520 Series is a shielded power inductor designed for high-current applications. It features a metal alloy powder core, high saturation current, flat wire construction, RoHS compliance, and halogen-free materials. These inductors are suitable for power supplies, DC-DC converters, and filtering circuits, providing low buzz noise and reliable performance across a temperature range of -40°C to +125°C. Compact and efficient, they optimize circuit stability and noise reduction in various electronic devices.
Bourns SRP0520R68K Power Inductor Specifications:
- Inductance: 0.68 µH
- Q: 17
- SRF: 25.2 MHz
- DcR: 0.78 Ω
- Irms: 9.0 A
- Isat: 10.7 A
- Dimensions: Length 5.8 mm, Width 5.4 mm, Height 2.5 mm
- Operating Temperature: -40 °C to +125 °C
- Rated Voltage: 50 V
- Moisture Sensitivity Level: Level A
- RoHS compliant and halogen-free
- Soldering Profile: Max. Peak Temperature 260 °C for 30 sec.
- Material: Metal alloy powder core with flat copper wire
Buy the Bourns Series SRP Power Inductor: SRP0520R68K
Enhance your power management system with the Bourns SRP0520 series power inductor, specially engineered for high current and noise reduction. Perfect for DC-DC conversion, switching power supplies, and filtering circuits, this shielded inductor offers excellent saturation current, RoHS compliance, and halogen-free construction. Its compact design ensures easy integration, reliable performance, and temperature stability from -40°C to +125°C. Order online today for high-quality, durable inductors that optimize your electronic device's efficiency and noise suppression.
Get Bourns SRP0520R68K today—built for power stability and long-lasting durability in your electronic designs.
Frequently Asked Questions
Where can I buy Bourns SRP0520R68K?
You can click on the BUY or RFQ button to purchase SRP0520R68K from an authorized Bourns distributor.
How do I troubleshoot issues or seek technical support for part SRP0520R68K?
You can download the SRP0520R68K datasheet or visit the Bourns website for support.
Who is the manufacturer of SRP0520R68K?
Bourns
