Bourns SRP0610R68K Power Inductor
The Bourns SRP0610 Series shielded power inductors feature a metal alloy powder core, high saturation current, low buzz noise, and a flat wire construction. RoHS compliant and halogen-free, these inductors are suitable for various power circuit applications, providing reliable inductance with excellent thermal and electrical performance. They are designed for high-frequency operation, with dimensions optimized for compact device layouts and efficient cooling. These inductors are ideal for use in power supplies, DC-DC converters, and other electronic systems requiring stable inductance and minimal noise.
Bourns SRP0610R68K Power Inductor Specifications:
- Core Material: Metal alloy powder
- Wire Material: Enamelled copper
- Terminal Finish: Tin
- Inductance: 0.68 μH
- Inductance Tolerance: 10%
- SRF: 25.2 MHz
- Dc Resistance (DCR): 55 mΩ
- Irms: 18 mA
- Isat: 47 A
- Operating Temperature Range: -40 °C to +125 °C
- Dimensions: 6.7 x 6.1 x 3.0 mm
- Peak Temperature: 260 °C max. during soldering
- Packaging: 2500 pcs per reel
- RoHS and Halogen Free: Yes
- Rated Voltage: 50 V
- Moisture Sensitivity Level: 1
- ESD Classification: N/A
Buy the Buy Bourns Shielded Power Inductor Part Number SRP0610R68K Online
Enhance your electronic projects with the Bourns SRP0610 series power inductor, featuring a shielded design, high saturation current, RoHS compliance, and halogen-free construction. Perfect for power supplies, DC-DC converters, and high-frequency circuits, this compact component ensures stable inductance and minimal noise. With a robust metal alloy powder core and enameled copper wire, these inductors deliver excellent thermal and electrical performance up to +125°C operating temperature. Order online now to secure reliable inductors for your demanding applications and improve device efficiency.
Buy Bourns SRP0610R68K now and experience unmatched reliability and high saturation current for power circuits.
