Bourns SRP4012TA8R2M Power Inductor
The SRP4012TA8R2M is a shielded power inductor designed for high-current applications in automotive and power supply systems. Featuring a carbonyl powder core, it offers high saturation current and low profile (1.0 mm), making it suitable for DC/DC converters, lighting, and driver assistance electronics. It is AEC-Q200 qualified, RoHS compliant, halogen-free, and capable of operating from -40°C to +150°C. The device provides various inductance options, high test voltage at 25°C, and reliable soldering profiles for robust electronic applications.
Bourns SRP4012TA8R2M Power Inductor Specifications:
- Inductance: 8.2 µH
- Test Voltage: 220 V at 25°C
- Operating Temperature Range: -40°C to +150°C
- Core: Carbonyl powder
- Mounting: Surface-mount (SMT)
- Max Peak Temperature during Soldering: 260°C for 40 sec.
- Dimensions: Diameter 0.120 inches (3.05 mm), Thickness 0.10 inches (2.54 mm)
- Material: Copper wire with RoHS-compliant halogen-free materials
- Reel Packaging: 4000 pieces per reel
- RoHS compliant and halogen free
- Saturation current depends on inductance and temperature
- Suitable for high-current power supply applications
- Mechanical: Low profile, compact size for space-constrained circuits
- Certification: RoHS, Halogen-Free, AEC-Q200 qualified
- Soldering Profile: Max temperature 260°C, max time 40 sec
- Application includes automotive modules, DC/DC converters, lighting, driver assistance
Buy the Bourns Series SRP Power Inductor: SRP4012TA8R2M
Purchase the Bourns SRP4012TA8R2M online today to ensure your automotive and power electronics projects are equipped with reliable, RoHS-compliant shielded inductors. Designed for high saturation current and low profile, it offers optimal performance from -40°C to +150°C. The device's robust construction guarantees durability, making it ideal for DC/DC converters, lighting systems, and driver assistance modules. Order now and benefit from quick delivery, quality assurance, and industry-leading specifications perfect for space-constrained applications.
Get Bourns SRP4012TA8R2M today—built for high-current automotive and power supply applications with reliable performance and RoHS compliance.
Frequently Asked Questions
Where can I buy Bourns SRP4012TA8R2M?
You can click on the BUY or RFQ button to purchase SRP4012TA8R2M from an authorized Bourns distributor.
How do I troubleshoot issues or seek technical support for part SRP4012TA8R2M?
You can download the SRP4012TA8R2M datasheet or visit the Bourns website for support.
Who is the manufacturer of SRP4012TA8R2M?
Bourns
