C&K COMPONENTS 400ECA01E Illuminated Tactile Switch
The illuminated tactile switch features multiple mounting styles including vertical, right-angle, and gull wing with J bend options. It operates with N.O. momentary action, offering an operating force of 160gf ± 50gf and a life cycle of 50,000 cycles. Suitable for various applications such as consumer electronics, medical devices, and security systems, it supports both thru-hole and SMT mounting with RoHS compliance. The switch includes LED illumination with a variety of colors and custom caps, and is designed for reliable electrical and mechanical performance in demanding environments.
C&K COMPONENTS 400ECA01E Illuminated Tactile Switch Specifications:
- FUNCTION: N.O. momentary action
- TERMINALS: SMT with positioning pegs, Thru-hole
- OPERATING FORCE: 160gf ± 50gf
- OPERATING LIFE: 50,000 cycles
- OPERATING TEMPERATURE: -25°C to +70°C
- STORAGE TEMPERATURE: -25°C to +80°C
- SOLDERABILITY: Thru-hole - wave compatible, SMT - convection or IR reflow compatible
- RECOMMENDED OPERATING STROKE: 0.25mm ± 0.1mm
- RATING: 50mA @ 12VDC
- CONTACT RESISTANCE: <100mΩ (initial)
- DIELECTRIC WITHSTANDING VOLTAGE: >250VAC between terminals
- INSULATION RESISTANCE: >100MΩ
- BOUNCE TIME: <10ms
- MATERIALS: CONTACTS/TERMINALS - brass with silver plating; BASE, ACTUATOR, COVER - PA
- PACKAGING: Thru-hole - 200 pieces per tray, SMT - tape & reel (500 pieces per reel)
- DIMENSIONS: Various mounting styles with dimensions shown in mm, subject to change
Buy the Generic Switch 400ECA01E – Reliable Illuminated Tactile Switch for Industrial Applications
Purchase the illuminated tactile switch 400ECA01E online today for high-quality performance in industrial, medical, and security systems. Designed with multiple mounting styles including vertical, right-angle, and gull wing, it features dual mounting options—thru-hole and SMT—for flexible integration. The switch provides a momentary N.O. contact with a 50,000-cycle life, robust electrical ratings, and a variety of LED colors for visual indication. Built with durable materials and RoHS compliance, it ensures reliable operation in a wide operating temperature range, making it ideal for demanding environments.
Buy the illuminated tactile switch 400ECA01E now and experience unmatched reliability, LED illumination options, and versatile mounting for demanding applications.
Frequently Asked Questions
Where can I buy C&K COMPONENTS 400ECA01E?
You can click on the BUY or RFQ button to purchase 400ECA01E from an authorized C&K COMPONENTS distributor.
How do I troubleshoot issues or seek technical support for part 400ECA01E?
You can download the 400ECA01E datasheet or visit the C&K COMPONENTS website for support.
Who is the manufacturer of 400ECA01E?
C&K COMPONENTS
