C&K COMPONENTS CR102J3AS215QF7 Time Delay Relay
The Amperite CR Series Time Delay Relay is designed for applications requiring precise timing control. It utilizes triggered delay on release timing mode, allowing for flexibility in control sequences. The relay offers SPST or SPDT contact configurations and features fixed or knob-adjustable timing selection, ranging from 1 to 600 seconds. The relay operates by requiring continuous input voltage to activate the internal relay, with the timing cycle beginning upon trigger input deactivation. Custom timing options are available to meet specific application requirements. It is suitable for industrial automation, process control, and other applications where timed relay operation is essential.
C&K COMPONENTS CR102J3AS215QF7 Time Delay Relay Specifications:
- Timing Mode: Input voltage must be applied continuously to operate the internal relay. Relay contacts transfer when the trigger input terminal is activated. The timing cycle begins when the trigger input terminal is deactivated.
- Contact Arrangement: 1 form A (SPST Normally open), 1 form B (SPST Normally closed), 1 form C (SPDT)
- Max Switching Power: 30W, 50VA
- Max Switching Voltage: 60V DC, 125V AC
- Max Switching Current: 1A DC, AC
- Max Carrying Current: 0.5A AC; 1A 30V DC
- UL File: E96739 (M)
- CSA File: LR62586
- Expected Life: 100,000 operations minimum at rated loads
- Operating Temperature Range: -25°C to +60°C (-13°F to +140°F)
- Termination Options: .110 inch (standard), .250 inch (optional), or screw terminals (optional)
- Enclosure: Black plastic case
- Mounting: Single screw or optional 2-screw panel mount
- Weight: 0.8 oz (23g)
- Fixed Timing Range: 1 through 600 secs.
- Timing Ranges: 1 - 120, 120 - 240, 240 - 480, 480 - 600 secs.
- Timing Adjustment: Knob adjustable potentiometer
- Timing Tolerance (Fixed): ±5%
- Timing Tolerance (Adjustable): -0 to +25% of maximum specified delay time
- Timing Repeatability: ±5%
- Release Time: 60 ms typical, 100 ms maximum
- Dielectric Strength (Open Contacts): 500V RMS
- Dielectric Strength (Contacts & Coil): 500V RMS
- Input Voltage (AC): 12V, 24V, and 115V
- Input Voltage (DC): 12V, 24V, 48V and 110V
- Power Requirement (AC): 2 VA or less
- Power Requirement (DC): 2 Watts or less
- Polarity Protection: On DC units - Yes
