C&K COMPONENTS CR102J3AS215QF8 Time Delay Relay
The Amperite CR Series Time Delay Relay is designed for applications requiring precise timing control. It utilizes solid-state analog circuitry and offers triggered delay on release timing. The relay contacts transfer when the trigger input terminal is activated, and the timing cycle begins when the trigger input is deactivated. Available with SPST (normally open) or SPDT contacts, the relay provides flexibility in circuit design. Timing can be fixed or adjusted via a knob potentiometer, with ranges from 1 to 600 seconds. Custom timing options are also available, making it suitable for a wide range of industrial automation, control systems, and other applications where precise timing is critical.
C&K COMPONENTS CR102J3AS215QF8 Time Delay Relay Specifications:
- Contact Arrangement: 1 form A (SPST Normally open), 1 form B (SPST Normally closed), 1 form C (SPDT)
- Max Switching Power: 30W, 50VA
- Max Switching Voltage: 60V DC, 125V AC
- Max Switching Current: 1A DC, AC
- Max Carrying Current: 0.5A AC; 1A 30V DC
- UL File: E96739 (M)
- CSA File: LR62586
- Expected Life: 100,000 operations minimum at rated loads
- Operating Temperature Range: -25°C to +60°C (-13°F to +140°F)
- Termination Options: .110 inch (standard), .250 inch (optional), or screw terminals (optional)
- Enclosure: Black plastic case
- Mounting: Single screw or optional 2-screw panel mount
- Weight: 0.8 oz (23g)
- Fixed Timing Range: 1 through 600 secs.
- Adjustable Timing Ranges: 1 - 120, 120 - 240, 240 - 480, 480 - 600 secs.
- Timing Adjustment: Knob adjustable potentiometer
- Timing Tolerance (Fixed): ±5%
- Timing Tolerance (Adjustable): -0 to +25% of maximum specified delay time
- Timing Repeatability: ±5%
- Release Time: 60 ms typical, 100 ms maximum
- Dielectric Strength (Open Contacts): 500V RMS
- Dielectric Strength (Contacts & Coil): 500V RMS
- Input Voltage (AC): 12V, 24V, and 115V
- Input Voltage (DC): 12V, 24V, 48V and 110V
- Power Requirement (AC): 2 VA or less
- Power Requirement (DC): 2 Watts or less
- Polarity Protection: On DC units - Yes
