C&K COMPONENTS CR102J4RS215QF7 Time Delay Relay
The Amperite CR Series Time Delay Relay is designed for applications requiring precise timing control. It utilizes triggered delay on release timing mode, where the relay contacts transfer when the trigger input terminal is activated, and the timing cycle begins upon deactivation. The relay de-energizes after the timing cycle completes, and the cycle can be reset by reactivating the trigger input. Available with fixed or knob-adjustable timing, this relay offers flexibility for various industrial applications. Custom timing configurations are also available to meet specific requirements.
C&K COMPONENTS CR102J4RS215QF7 Time Delay Relay Specifications:
- Contact Arrangement: 1 form A (SPST Normally open), 1 form B (SPST Normally closed), 1 form C (SPDT)
- Max Switching Power: 30W, 50VA
- Max Switching Voltage: 60V DC, 125V AC
- Max Switching Current: 1A DC, AC
- Max Carrying Current: 0.5A AC; 1A 30V DC
- UL File: E96739 (M)
- CSA File: LR62586
- Expected Life: 100,000 operations minimum at rated loads
- Operating Temperature Range: -25°C to +60°C (-13°F to +140°F)
- Termination Options: .110 inch (standard), .250 inch (optional), or screw terminals (optional)
- Enclosure: Black plastic case
- Mounting: Single screw or optional 2-screw panel mount
- Weight: 0.8 oz (23g)
- Timing - Fixed: 1 through 600 secs.
- Timing Ranges: 1 - 120, 120 - 240, 240 - 480, 480 - 600 secs.
- Timing Adjustment: Knob adjustable potentiometer
- Timing Tolerance: Fixed Units: ±5%; Adjustable Units: -0 to +25% of maximum specified delay time
- Timing Repeatability: ±5%
- Release Time: 60 ms typical, 100 ms maximum
- Initial Dielectric Strength: 500V RMS (Between open contacts), 500V RMS (Between contacts & coil)
- Input Voltage (AC): 12V, 24V, and 115V
- Input Voltage (DC): 12V, 24V, 48V and 110V
- Power Requirement (AC): 2 VA or less
- Power Requirement (DC): 2 Watts or less
- Polarity Protection: Yes (on DC units)
