C&K COMPONENTS E121SD1A3GE Sealed Momentary Pushbutton
The C&K E121SD1A3GE is a sealed snap-acting momentary pushbutton switch suitable for applications requiring a robust and reliable switching solution. It incorporates a long-life contact design to ensure durability and consistent performance. Available in RoHS compliant models, this switch caters to environmentally conscious designs. The inclusion of a disposable splashproof boot provides added protection against moisture and contaminants, making it ideal for harsh environments. Typical applications include instrumentation, telecommunications equipment, and computers.
C&K COMPONENTS E121SD1A3GE Sealed Momentary Pushbutton Specifications:
- Contact Rating: 0.4 VA max. @ 20 V AC or DC (B contact material), 1 AMP @120 V AC or 28 V DC (G contact material)
- Case & Bushing: Glass filled nylon 6/6, flame retardant (UL 94V-0)
- Plunger: Glass filled nylon or glass filled polyester (PBT) (UL 94V-0)
- Switch Support: Brass or steel, matte-tin
- Switch Support Retainer: Stainless steel
- Electrical Life: 60,000 make-and-break cycles
- N.O. & N.C. Contacts (EX25): Copper alloy, with gold plate over nickel plate
- N.O. & N.C. Contacts (EX21): Coin silver, with gold plate over nickel plate
- Contact Resistance: Below 50 mΩ typ. initial @ 2–4 V DC, 100 mA
- Insulation Resistance: 10[9] Ω min.
- Dielectric Strength: 1000 Vrms min. @ sea level
- Common Contacts & Terminals: Copper alloy, with gold plate over nickel plate
- Operating Temperature: –30ºC to 75ºC
- Cap Installation Force: 10 lbs. max. permissible
- Terminal Seal: Epoxy
- Solderability: Per MIL-STD-202F method 208D or EIA RS-186E method 9
- Disposable Boot: Vinyl splashproof boot
- RoHS Compliant Models: Available
