C&K COMPONENTS E221SD3V6GE Sealed Snap-acting Pushbutton Switch
The C&K E020 Series Sealed Snap-acting Momentary Pushbutton Switches offer a robust and reliable solution for a wide range of applications. These switches are designed with a sealed construction to protect against moisture and contaminants, making them suitable for use in demanding environments. Key features include a long-life contact design, snap-fitting plunger options, and RoHS compliant models. They are commonly used in instrumentation, telecommunications equipment, computers, and peripherals where reliable switching performance is critical. The switches are available with various contact materials, plunger heights, bushing types, and termination options to meet specific application requirements.
C&K COMPONENTS E221SD3V6GE Sealed Snap-acting Pushbutton Switch Specifications:
- Contact Rating: 0.4 VA max. @ 20 V AC or DC (B contact material) or 1 AMP @120 V AC or 28 V DC (G contact material)
- Case & Bushing: Glass filled nylon 6/6, flame retardant (UL 94V-0)
- Plunger: Glass filled nylon or glass filled polyester (PBT) (UL 94V-0)
- Switch Support: Brass or steel, matte-tin
- Switch Support Retainer: Stainless steel
- Electrical Life: 60,000 make-and-break cycles at full load
- N.O. & N.C. Contacts (EX25 Models): Copper alloy, with gold plate over nickel plate
- N.O. & N.C. Contacts (EX21 Models): Coin silver, with gold plate over nickel plate
- Contact Resistance: Below 50 mΩ typ. initial @ 2–4 V DC, 100 mA
- Insulation Resistance: 10[9] Ω min.
- Dielectric Strength: 1000 Vrms min. @ sea level
- Common Contacts & Terminals: Copper alloy, with gold plate over nickel plate
- Operating Temperature: –30ºC to 75ºC
- Cap Installation Force: 10 lbs. max. permissible
- Terminal Seal: Epoxy
- Solderability: Per MIL-STD-202F method 208D or EIA RS-186E method 9
- Disposable Boot: Vinyl splashproof boot
- RoHS Compliant Models: Available
- Switch Function: DPDT On-Mom. 1 Amp
