C&K COMPONENTS ILSTC18030 LED Tactile Switch
The ILS Series integrated LED tactile switch features a compact design with multiple height options and LED color choices for versatile applications. Designed for consumer electronics, health monitoring, and audio/video control, it offers high durability with a mechanical life of 100,000 cycles. The switch operates efficiently across -40°C to +85°C and includes physical and electrical specifications such as 0.25 mm travel, rated current of 100mA at 30VDC, and dielectric withstand voltage of 250VAC. It is available in bulk packaging for easy integration into various electronic devices, with options for different actuation forces and LED colors for customization.
C&K COMPONENTS ILSTC18030 LED Tactile Switch Specifications:
- Travel: 0.25 mm ± 0.1 mm
- Operating Life: 100,000 cycles
- Rating: 100mA max. @ 30VDC, 10pA min. @ 1VDC
- Insulation Resistance: 100MΩ min.
- Dielectric Withstanding Voltage: 250VAC (50-60Hz 2mA) for 1 min
- Bounce Time: ON/OFF 5ms max.
- Initial Contact Resistance: 100mΩ max.
- Operating Temperature: -40°C to +85°C
- Storage Temperature: -40°C to +85°C
- Physical Dimensions vary by style and height options, with key options being 7.00 mm, 7.20 mm, and 9.00 mm in height
- LED Power Dissipation: 52-120 mW depending on color
- Forward Current: 5-30 mA depending on LED color
- Forward Voltage: 2.3 to 3.6 V depending on LED color
- Peak Forward Current: 100 mA
- Spectral Wavelength: 460-644 nm depending on LED color
- Viewing Angle: 35°
Buy the Buy LED Tactile Switch Part Number ILSTC18030 Online
Discover the versatile LED tactile switch designed for reliable operation in consumer electronics, health devices, and control panels. The switch offers various heights and LED colors, supporting up to 100,000 cycles. With specifications including 0.25 mm travel, rated current of 100mA at 30VDC, and dielectric withstand voltage of 250VAC, it ensures durability across a wide temperature range. Ideal for integrators seeking compact, customizable switches, available in bulk packs for efficient assembly and deployment.
Buy LED Tactile Switch ILSTC18030 now and experience unmatched reliability, diverse LED colors, and high cycle durability for your electronic projects.
Frequently Asked Questions
Where can I buy C&K COMPONENTS ILSTC18030?
You can click on the BUY or RFQ button to purchase ILSTC18030 from an authorized C&K COMPONENTS distributor.
How do I troubleshoot issues or seek technical support for part ILSTC18030?
You can download the ILSTC18030 datasheet or visit the C&K COMPONENTS website for support.
Who is the manufacturer of ILSTC18030?
C&K COMPONENTS
