C&K COMPONENTS KSL0M312LFT sealed tactile switch
The KSL0M312LFT tactile switch features a compact design with a 2.5 mm height, ideal for space-constrained applications like wearables, IoT devices, and sensors. It offers a momentary SPST N.O. contact with a high cycle life of 200,000 operations. Constructed with durable silver contact material and RoHS compliance, it operates effectively in a temperature range of -40°C to 85°C. Suitable for SMT mounting with gullwing terminals, it is sealed to IP67, providing excellent reliability in industrial, medical, and consumer electronics environments.
C&K COMPONENTS KSL0M312LFT sealed tactile switch Specifications:
- Physical Dimensions: Height 2.5 mm, Footprint 5.2 x 5.2 mm
- Contact Material: Silver
- Contact Resistance: < 100 mΩ
- Insulation Resistance: > 100 MΩ
- Dielectric Strength: > 250 Vrms
- Maximum Power: 1 VA
- Maximum Voltage: 32 VDC
- Maximum Current: 50 mA
- Operating Temperature: -40°C to 85°C
- Sealing: IP67
- Mechanical Life: 200,000 operations
- Soldering Method: Infrared reflow per IEC61760-1
- Mounting Type: SMT with gullwing terminals
Buy the CK Switches KSL0M312LFT – Reliable Sealed Tactile Switch for Industrial Applications
Order the CK Switches KSL0M312LFT today—an ultra-compact, IP67 sealed tactile switch designed for space-efficient applications like wearables, medical devices, and industrial automation. Its 2.5 mm height, silver contact material, and high cycle life of 200,000 operations ensure reliable performance across temperature ranges of -40°C to 85°C. Compatible with SMT mounting using gullwing terminals, this RoHS-compliant switch offers excellent durability, IP67 sealing, and ease of installation for demanding industrial, medical, and consumer electronic projects.
Get CK Switches KSL0M312LFT today—built for durability and high cycle life in IoT and industrial environments.
Frequently Asked Questions
Where can I buy C&K COMPONENTS KSL0M312LFT?
You can click on the BUY or RFQ button to purchase KSL0M312LFT from an authorized C&K COMPONENTS distributor.
How do I troubleshoot issues or seek technical support for part KSL0M312LFT?
You can download the KSL0M312LFT datasheet or visit the C&K COMPONENTS website for support.
Who is the manufacturer of KSL0M312LFT?
C&K COMPONENTS
