C&K COMPONENTS LP82C31T203DQ Miniature Slide Switch
The C&K LP82C31T203DQ is a miniature snap-in slide switch designed for a wide range of applications including small appliances, outdoor appliances, and portable tools. Constructed with a durable 6/6 nylon housing and a glass-filled acetal actuator resistant to petroleum, this switch provides reliable performance and ease of assembly. The silver-plated copper contacts offer excellent conductivity, while the positive detent ensures a secure connection. Available with various options for mounting style, actuator cap color, and housing markings, the LP82C31T203DQ offers versatility for diverse design requirements. It is RoHS compliant and designed to meet the demands of modern electronic systems.
C&K COMPONENTS LP82C31T203DQ Miniature Slide Switch Specifications:
- Contact Rating: Q contact material: 6 AMPS @ 125 V AC or 28 V DC; 3 AMPS @ 250 V AC (UL/CSA) for LP0X, LP2X Models. 11 AMPS @ 125/250 V AC (UL/CSA) for LP7X, LP8X Models
- Electrical Life: 10,000 make-and-break cycles at full load
- Insulation Resistance: 10[9] Ω min
- Dielectric Strength: 1,000 Vrms min. @ sea level
- Contact Resistance: Below 10 m Ω typ. initial @ 2-4 V DC, 100 mA
- Housing Material: 6/6 nylon (UL94V-2), black
- Actuator Material: Glass filled acetal, UV and petroleum resistant, black
- Contact Material: Copper, silver plated
- Terminal Material: Copper, silver plated
- Operating Temperature: -30ºC to +65ºC
- Storage Temperature: -30ºC to +85ºC
- Mounting Style: Snap-in panel with tabs
- Termination: Solder lug with hole
