C&K COMPONENTS PNP8S2D2C03QE Micro Snap-Acting Switch
The C&K COMPONENTS MDS series micro snap-acting detect switches offer a snap-acting tactile feel in a compact package. These switches are designed for various applications, including medical devices, consumer electronics, and ATCA systems. They are RoHS compliant and available with different mounting options and termination styles to meet diverse design requirements. The switches feature a mechanical and electrical life of 30,000 operations and a contact resistance of 100 mΩ max. They are constructed with PA9T for the base, cover, and actuator, and copper alloy with silver plating for the movable and stationary contacts, and terminals.
C&K COMPONENTS PNP8S2D2C03QE Micro Snap-Acting Switch Specifications:
- Contact Rating: 300mA @ 30 VDC
- Mechanical & Electrical Life: 30,000 operations
- Contact Resistance: 100 m Ω max
- Operating Temperature: -25ºC to +70ºC
- Operating Force: 50g Max
- Release Force: 3g Min
- Base Material: PA9T
- Cover & Actuator Material: PA9T
- Movable Contact Material: Copper alloy, silver plated
- Stationary Contact Material: Copper alloy, silver plated
- Terminal Material: Copper alloy, silver plated
Buy the PNP8S2D2C03QE C&K COMPONENTS Micro Snap-Acting Switch | myMectronic
Purchase the C&K COMPONENTS PNP8S2D2C03QE Micro Snap-Acting Detect Switch securely and efficiently online.
Buy Now
Frequently Asked Questions
Where can I buy C&K COMPONENTS PNP8S2D2C03QE?
You can click on the BUY or RFQ button to purchase PNP8S2D2C03QE from an authorized C&K COMPONENTS distributor.
How do I troubleshoot issues or seek technical support for part PNP8S2D2C03QE?
You can download the PNP8S2D2C03QE datasheet or visit the C&K COMPONENTS website for support.
Who is the manufacturer of PNP8S2D2C03QE?
C&K COMPONENTS
