C&K COMPONENTS PVA1EEH112NV2 Short Stroke Key Switch
The C&K COMPONENTS PVA1 EE H1 1.2N V2 is a short-stroke key switch designed for versatility and reliability in various applications. Its compact design and short stroke to latch mechanism make it ideal for space-constrained environments. The switch is adaptable for medium power applications and finds use in automotive systems like air conditioning and lighting, as well as industrial control panels. It offers a wide variety of actuator heights to suit different user preferences and panel requirements. RoHS compliant for environmentally conscious designs.
C&K COMPONENTS PVA1EEH112NV2 Short Stroke Key Switch Specifications:
- Features: ['Compact design', 'Short stroke to latch', 'Wide variety of actuator heights', 'Adapted for medium power applications']
- Typical Applications: ['Automotive (air conditioning, lighting)', 'Industrial', 'Control panel']
- Function: Momentary, Push-Push
- Contact Arrangement: 2 make contacts (DPST)
- Switching Mode: Non-shorting
- Terminals: PC pins
- Total Travel/Latching Travel: OA: 2.4 mm, EE: 2.4 / 1.5 mm
- Electrical Travel: 0.8 mm (1.1 for PVA2 OA H5)
- Operating Force: 1.2N, 1.7N, 3.5N
- Switching Power Max: 3 W DC
- Switching Voltage Max: 32 V DC
- Switching Current Max: 100 mA DC
- Dielectric Strength: 1000 V between open contacts (PVA2: 750 V)
- Operating Life: ≥ 1 x 10[5] operations (OA & EE)
- Contact Resistance: Initial ≤ 100 mΩ
- Insulation Resistance: ≥ 10[10] Ω
- Bounce Time: ≤ 3 ms
- Operating Temperature: -40˚C to 85˚C
- Solderability: Wave soldering (lead-free compatible), Hand soldering (350˚C for 3 seconds)
