C&K COMPONENTS SD04H0SBR Low Profile DIP Switch
The SD Series Low Profile DIP Switches are space-saving, sealed switches suitable for industrial controls, computer logic, and peripheral management. available in thru-hole and surface mount configurations, their RoHS compliance and tape-sealed design ensure durability during soldering and cleaning processes. They feature SPST contact function with multiple positions, a contact rating of 100 mA at 50 V DC, and a mechanical life of 2,000 cycles. Constructed with flame-retardant materials, they offer reliable operation in temperatures from -40°C to 85°C, making them ideal for compact, high-density applications.
C&K COMPONENTS SD04H0SBR Low Profile DIP Switch Specifications:
- Function: SPST with 2, 3, 4, 5, 6, 7, 8, 9, 10 & 12 positions
- Contact Rating: 100 mA @ 50 V DC max, switch: 0.1 mA @ 5 V DC min to 100 mA @ 25 V DC max
- Mechanical & Electrical Life: 2,000 cycles
- Contact Resistance: Below 50 milliohms initial
- Insulation Resistance: 10^8 ohms
- Dielectric Strength: 500 V RMS min
- Operating Temperature: -40°C to 85°C
- Storage Temperature: -40°C to 85°C
- Material: PPA case & cover, nylon actuator, gold-plated BeCu contacts, tin-plated brass terminals
- Dimensions vary: typical actuator travel 0.97 inches, tape and reel packaging for surface mount options
Buy the CK Switches Series Low Profile DIP Switch: SD04H0SBR
Purchase the CK Switches Low Profile DIP Switch SD04H0SBR online today for space-saving, durable switching solutions. Ideal for industrial controls and electronic projects, this switch offers multiple positions, sealed design, and RoHS compliance. Available in thru-hole and surface mount configurations, its robust construction ensures reliable operation through 2,000 cycles. Easy to integrate into compact designs, this switch enhances your projects with dependable performance under diverse temperature conditions. Buy now for quick delivery and seamless integration into your control and automation systems.
Order your CK Switches Series Low Profile DIP Switch SD04H0SBR today and ensure space-efficient, reliable switching for your electronic control needs.
Frequently Asked Questions
Where can I buy C&K COMPONENTS SD04H0SBR?
You can click on the BUY or RFQ button to purchase SD04H0SBR from an authorized C&K COMPONENTS distributor.
How do I troubleshoot issues or seek technical support for part SD04H0SBR?
You can download the SD04H0SBR datasheet or visit the C&K COMPONENTS website for support.
Who is the manufacturer of SD04H0SBR?
C&K COMPONENTS
