C&K COMPONENTS SDA05H0BD Low Profile DIP Switch
The SDA series low profile 5-position surface-mount DIP switch features a compact design that saves space. It has a flush actuator with gull-wing terminations, gold-plated beryllium copper contacts, and gold plating over nickel-plated brass terminals. The switch offers a mechanical and electrical lifespan of 1,000 cycles at rated loads, with an insulation resistance of 100 MΩ between terminals and a maximum initial contact resistance of 50 mΩ. It can withstand a dielectric voltage of at least 300 VDC for one minute. The actuator is made of black-colored PA6T (UL94-0), and the cover and housing are made of PPS (UL94V-0). It is suitable for use as an address switch in industrial controls, computer, and peripheral switching applications requiring reliable function control.
C&K COMPONENTS SDA05H0BD Low Profile DIP Switch Specifications:
- Contact Rating: 25 mA @ 24 V DC or 100 mA @ 5 V DC
- Mechanical and Electrical Life: 1,000 cycles at rated loads
- Contact Resistance: 50 mΩ max. initial
- Insulation Resistance: 100 MΩ between terminals
- Dielectric Withstanding Voltage: 300 V DC min. for 1 minute
- Storage Temperature: -40°C to 85°C
- Operating Temperature: -40°C to 85°C
- Operating Force: 800 grams max
- Housing Material: PPS, UL94V-0
- Cover Material: PPS, UL94V-0
- Actuator Material: PAGT (UL94-0)
- Contacts: Gold plated Beryllium copper
- Terminals: Gold plate over nickel plated brass
- Packaging: Rigid dispensing tubes, tape and reel options available
Buy the CK Series SDA: Low Profile DIP Switch: SDA05H0BD
Order the CK SDA05H0BD low profile surface-mount DIP switch online today and enhance your control applications with its durable design, gold-plated contacts, and space-saving profile. Perfect for industrial controls, peripherals, and where space efficiency is crucial. Enjoy fast delivery and quality assurance by purchasing directly from authorized suppliers. This switch offers dependable performance over thousands of cycles, ensuring longevity and consistent operation in demanding environments. Make your control system more reliable by choosing this low profile, high-quality DIP switch today.
Buy CK SDA05H0BD low profile surface-mount DIP switch now and experience reliable switching performance for industrial and computer control needs.
Frequently Asked Questions
Where can I buy C&K COMPONENTS SDA05H0BD?
You can click on the BUY or RFQ button to purchase SDA05H0BD from an authorized C&K COMPONENTS distributor.
How do I troubleshoot issues or seek technical support for part SDA05H0BD?
You can download the SDA05H0BD datasheet or visit the C&K COMPONENTS website for support.
Who is the manufacturer of SDA05H0BD?
C&K COMPONENTS
