C&K COMPONENTS SDA06H1SBD Low Profile DIP Switch
The SDA series low-profile 6-position surface-mount DIP switch features a compact design that saves space. It has an extended actuator with gull-wing terminations, made with gold-plated beryllium copper contacts and gold over nickel-plated brass terminals. The switch offers a mechanical and electrical life of 1,000 cycles at rated loads, with an insulation resistance of 100 MΩ between terminals and a maximum initial contact resistance of 50 mΩ. It withstands a dielectric voltage of at least 300VDC for one minute. The actuator is made of UL94V-0 rated PA6T material in black, with a cover and housing also rated UL94V-0. This switch is suitable for address selection in industrial control systems, as well as switching functions in computers and peripherals, serving various control applications.
C&K COMPONENTS SDA06H1SBD Low Profile DIP Switch Specifications:
- Contact Rating: 25 mA @ 24 V DC or 100 mA @ 5 V DC
- Mechanical and Electrical Life: 1,000 cycles
- Contact Resistance: 50 mΩ max. initial
- Insulation Resistance: 100 MΩ between terminals
- Dielectric Withstanding Voltage: 300 V DC min. for 1 minute
- Storage Temperature: -40°C to 85°C
- Operating Temperature: -40°C to 85°C
- Operating Force: 800 grams max
- Housing Material: PPS, UL94V-0 rated, black
- Cover Material: PPS, UL94V-0 rated, black
- Actuator Material: PAGT, UL94V-0
- Contact Material: Gold plated beryllium copper
- Terminals Material: Gold over nickel-plated brass
Buy the Buy C&K Low Profile DIP Switch Part Number SDA06H1SBD Online
Experience seamless control and reliability with C&K's low profile surface-mount DIP switch. Designed for high-density applications, it features 6 positions with gull-wing terminations and gold-plated contacts for enhanced conductivity. Its compact, space-saving design makes it perfect for industrial controls, computer peripherals, and electronic switching functions. Engineered for a life cycle of 1,000 cycles, it withstands demanding electrical environments. Easily order online and enjoy fast delivery, ensuring your projects stay on schedule with dependable, high-quality components.
Get C&K SDA06H1SBD today—compact surface-mount switch, ideal for industrial and electronic control applications, built for durability and precision.
Frequently Asked Questions
Where can I buy C&K COMPONENTS SDA06H1SBD?
You can click on the BUY or RFQ button to purchase SDA06H1SBD from an authorized C&K COMPONENTS distributor.
How do I troubleshoot issues or seek technical support for part SDA06H1SBD?
You can download the SDA06H1SBD datasheet or visit the C&K COMPONENTS website for support.
Who is the manufacturer of SDA06H1SBD?
C&K COMPONENTS
