C&K COMPONENTS SDA10H1SBD Surface Mount DIP Switch
The SDA1 series low profile 10-position surface-mount DIP switch features a compact design that saves space. It has an extended actuator with gull-wing terminations, made with gold-plated beryllium copper contacts and gold plating over nickel-plated brass terminals. The switch offers a mechanical and electrical lifespan of 1,000 cycles at rated loads, with an insulation resistance of 100 MΩ between terminals and a maximum initial contact resistance of 50 mΩ. It can withstand a dielectric voltage of at least 300VDC for 1 minute. The actuator is made from UL94-V0 rated PA6T (black), and the cover and housing are also UL94V-0 rated PPS. It is suitable for applications such as address switching in industrial controls, computer, and peripheral switching, providing reliable control functions across various uses.
C&K COMPONENTS SDA10H1SBD Surface Mount DIP Switch Specifications:
- Contact Rating: 25 mA @ 24 V DC or 100 mA @ 5 V DC
- Mechanical and Electrical Life: 1,000 cycles at rated loads
- Contact Resistance: 50 mΩ max. initial
- Insulation Resistance: 100 MΩ between terminals
- Dielectric Withstanding Voltage: 300 V DC min. for 1 minute
- Storage Temperature: -40°C to 85°C
- Operating Temperature: -40°C to 85°C
- Operating Force: 800 grams max
- Housing Material: PPS, UL94V-0
- Cover Material: PPS, UL94V-0
- Actuator Material: PAGT, UL94-0
- Contacts: Gold plated Beryllium copper
- Terminals: Gold over nickel plated brass
Buy the Buy C&K SDA10H1SBD Part Number SDA10H1SBD Online
Experience reliable switching with the C&K SDA10H1SBD surface mount DIP switch. Designed for industrial controls, computer peripherals, and electronic applications, it features extended gull-wing terminations, gold-plated contacts, and UL94V-0 rated materials for safety and durability. Capable of 1,000 cycles, with 50 mΩ initial contact resistance, and a dielectric withstand of 300VDC, this switch ensures long-term performance in various environments. Its compact design saves space while providing dependable control functions for diverse electronic projects and manufacturing applications.
Get C&K SDA10H1SBD today—built for precision and long-lasting durability in electronic control systems.
Frequently Asked Questions
Where can I buy C&K COMPONENTS SDA10H1SBD?
You can click on the BUY or RFQ button to purchase SDA10H1SBD from an authorized C&K COMPONENTS distributor.
How do I troubleshoot issues or seek technical support for part SDA10H1SBD?
You can download the SDA10H1SBD datasheet or visit the C&K COMPONENTS website for support.
Who is the manufacturer of SDA10H1SBD?
C&K COMPONENTS
