C&K COMPONENTS TDP08H0SB1 surface-mount DIP switch
The TDP series is a four-position, ultra-miniature surface-mount half-pitch side-actuated DIP switch. It features side actuation for easy visual identification of on/off states in horizontal applications. The switch is process sealed for surface mounting and washable processing. It offers a mechanical and electrical lifespan of 1,000 cycles, with an insulation resistance of at least 100 MΩ at 100 VDC, and a maximum contact resistance of 100 mΩ. The dielectric strength is rated at a minimum of 300 VAC. Suitable for use in hand-held electronic devices, instrumentation, controls, portable computers, and other electronic applications.
C&K COMPONENTS TDP08H0SB1 surface-mount DIP switch Specifications:
- Switch Function: SPST — 2, 4, 6, 8, 10 positions
- Case & Cover: glass filled PPS (UL94V-0)
- Contact Rating: 24 V DC, 25 mA (switching); 50 V DC, 100 mA (steady state)
- Mechanical and electrical life: 1,000 cycles
- Contact Resistance: 100 mΩ max
- Insulation Resistance: 100 MΩ min at 100 V DC
- Dielectric Strength: 300 V AC min
- Storage Temperature: ~40°C to 85°C
- Operating Temperature: ~40°C to 85°C
- Operating Force: 4.9 N max
- Material: PA6T actuator (UL94V-0), glass-filled PPS case & cover
- Solderability: Per MIL-STD-202F method 208D or EIA RS-186E
- Package options: Tubes, Tape and Reel
Buy the CK Switches TDP08H0SB1 – Reliable Surface-Mount DIP Switch for Industrial Applications
Enhance your electronic assemblies with our reliable surface-mount DIP switch featuring side actuation for easy visual state indication. Designed for high durability, it withstands 1,000 cycles of operation, with excellent insulation resistance and dielectric strength. Suitable for handheld devices, instrumentation, controls, and portable computers, this sealed switch offers easy soldering, washable processing, and multiple packaging options. Upgrade your projects with this compact, high-performance switch for consistent, dependable switching performance in tight spaces and demanding environments.
Order your CK Series TDP08H0SB1 ultra-miniature DIP switch today and ensure precise, reliable switching in your surface-mount electronic projects.
Frequently Asked Questions
Where can I buy C&K COMPONENTS TDP08H0SB1?
You can click on the BUY or RFQ button to purchase TDP08H0SB1 from an authorized C&K COMPONENTS distributor.
How do I troubleshoot issues or seek technical support for part TDP08H0SB1?
You can download the TDP08H0SB1 datasheet or visit the C&K COMPONENTS website for support.
Who is the manufacturer of TDP08H0SB1?
C&K COMPONENTS
