CARLO GAVAZZI RAM1A60A125 Industrial Solid State Relay
The industrial solid state relay RAM1A60A125 from Carlo Gavazzi is a reliable, high-performance device designed for controlling resistive, inductive, and capacitive loads on 1-phase systems. Featuring zero cross switching, direct copper bonding technology, LED status indicators, and overvoltage protection, it ensures efficient operation in demanding industrial environments. Suitable for AC loads up to 125 amperes, with control voltages between 20-280 VAC or 22-48 VDC, it is protected against transient voltages and offers IP20 touch protection, making it an ideal choice for automation and control applications.
CARLO GAVAZZI RAM1A60A125 Industrial Solid State Relay Specifications:
- Switching Mode: Zero Switching
- Rated Operational Voltage: 20-280 VAC/22-48 VDC
- Control Voltage Range: 3-32 VDC or 20-280 VAC/DC depending on type
- Rated Operational Current: 125A
- Blocking Voltage: Up to 1600 Vp
- Input to Output Isolation: > 4000 VACrms
- Housing Material: Noryl, black
- Housing Weight: Approx. 100g
- Ambient Temperature Range: -40°C to +80°C
- Maximum Junction Temperature: 125°C
- Environmental Protection: IP20
- Protection: Overvoltage by self-switching (suffix Z)
Buy the Carlo Gavazzi Series Solid State Relay: 125A Control Voltage 20-280VAC RAM1A60A125
Discover the high-performance Carlo Gavazzi RAM1A60A125 solid state relay, perfect for industrial automation. It features zero cross switching, LED status indication, and overvoltage protection, handling loads up to 125A at control voltages of 20-280VAC/DC. Its IP20 housing provides touch protection, suitable for resistive, inductive, and capacitive loads. Easy to install with robust copper bonding technology and applicable in various control systems. Order now online for dependable operation and seamless integration into your automation setup.
Buy Carlo Gavazzi RAM1A60A125 now and experience unmatched reliability and high load capacity for your industrial automation needs.
Frequently Asked Questions
Where can I buy CARLO GAVAZZI RAM1A60A125?
You can click on the BUY or RFQ button to purchase RAM1A60A125 from an authorized CARLO GAVAZZI distributor.
How do I troubleshoot issues or seek technical support for part RAM1A60A125?
You can download the RAM1A60A125 datasheet or visit the CARLO GAVAZZI website for support.
Who is the manufacturer of RAM1A60A125?
CARLO GAVAZZI
