CARLO GAVAZZI RAM1B60D100 Industrial Solid State Relay
The RAM1B60D100 is a reliable industrial 1-phase solid state relay featuring instant-on switching mode, AC control voltage range of 20-280 VAC, and rated operational current of 100A. Equipped with LED indication and overvoltage protection, it supports resistive, inductive, and capacitive loads for versatile industrial automation applications. Its sealed housing ensures protection, while its high blocking voltage up to 1600 Vp and opto-isolation over 4000 VACrms guarantee safe and efficient operation in demanding environments. Suitable for phase angle control with built-in transient protection.
CARLO GAVAZZI RAM1B60D100 Industrial Solid State Relay Specifications:
- Switching Mode: Instant-on switching
- Rated Operational Voltage: 20-280 VAC / 22-48 VDC
- Control Voltage Range: 4-32 VDC
- Rated Operational Current: 100 AACrms
- Blocking Voltage: Up to 1600 Vp
- Opto-isolation: > 4000 VACrms
- Overvoltage Protection: Yes, self-switching (suffix Z option)
- Housing Material: Noryl, black, sealed, IP20 protected
- Housing Weight: Approx. 100g
- Connections: M8 screw terminals with captivated washers
- Mounting: DIN rail or panel mounting
- Ambient Temperature Range: -40°C to +80°C
- Maximum Case Temperature: 100°C
- Maximum Junction Temperature: 125°C
- Approvals: UL, cUR, CSA, VDE, CE, UKCA
- Mechanical Dimensions: Refer to datasheet for detailed size specifications
Buy the Carlo Gavazzi RAM1B60D100 – Reliable Instant-On Solid State Relay for Industrial Applications
Purchase the Carlo Gavazzi RAM1B60D100 online today and experience superior load switching, fast response times, and robust protection features ideal for industrial automation. Designed for resistive, inductive, and capacitive loads, this relay supports control voltages from 20-280 VAC and currents up to 100A, ensuring reliable operation in demanding environments. Its compact sealed IP20 housing with LED indication simplifies installation and maintenance, while overvoltage protection ensures long-term durability. Order now to enhance your automation system’s efficiency and safeguard your operations.
Get Carlo Gavazzi RAM1B60D100 today—built for precision, fast switching, and long-lasting durability in industrial automation systems.
Frequently Asked Questions
Where can I buy CARLO GAVAZZI RAM1B60D100?
You can click on the BUY or RFQ button to purchase RAM1B60D100 from an authorized CARLO GAVAZZI distributor.
How do I troubleshoot issues or seek technical support for part RAM1B60D100?
You can download the RAM1B60D100 datasheet or visit the CARLO GAVAZZI website for support.
Who is the manufacturer of RAM1B60D100?
CARLO GAVAZZI
